These operating instructions are an integral part of the
product. They contain important information and safety
notes, and should be kept in a safe place at all times. Be
sure to pass them on to the new owner if you ever dispose
of the product.
1. I
NTRODUCTION
The brushless TUNING power set for the Solius offers the
advanced pilot an ample amount of excess power with a
3S LiPo battery - ideal for simple aerobatics and windy
weather.
2. C
/ R
ONTENTS
EPLACEMENT PARTS
• 1 PERMAX BL-O 3516-0850
• 1 MULTIcont BL-40 S-BEC speed controller
• 1 MULTIPLEX Li-BATT FX 3/1-2200
3. T
. O
YP
PERATIONAL
"S
"
OLIUS
3S LiPo / MPX 12" x 6" folding prop
approx. 27 A
Recommended flight battery:
MULTIPLEX Li-BATT FX 3/1-2200
Do not use the supplied PERMAX BL-O 3516-0850 motor
with more than 3S LiPo or 9 NiXX cells when using the
recommended propellers.
4. S
N
AFETY
OTES
The power set "Solius" is designed exclusively for use in
modelling applications. Incorrect use can result in serious
personal injury.
• Read the instructions before initiation
• Before every flight, check that the motor and propeller
are securely mounted
• Remove all movable objects from the area around the
propeller before switching the motor on
• Do not allow clothing or any of your extremities to get
close to the spinning propeller
• Never start running the motor in your hand
• Stop the motor immediately if you notice vibration.
Eliminate the cause of the vibration before running it
again; you may need to correct the balance of the
propeller blades
• Make sure the power system is adequately cooled; do
not allow anything to obstruct the free circulation of air
MULTIPLEX Modellsport GmbH & Co.KG • Westliche Gewerbestraße 1 • D-75015 Bretten • www.multiplex-rc.de
Operating Instructions for Power Set "Solius"
# 33 3231
# 7 2285
# 15 7351
D
P
S
ATA OF
OWER
ET
Current drain:
# 15 7351
5. A
T
SSEMBLING
HE
Install the motor as described in the model's building
instructions, then fit the speed controller in the motor pod.
Ensure that no cables can foul or rub against the motor's
spinning case.
6. I
NITIATION OF THE
1. Connect the three wires attached to the speed
controller to the three wires attached to the motor; the
order of connection is unimportant.
2. Locate the UNI connector attached to the speed
controller, and connect it to your receiver.
3. Switch the transmitter on, and check that the throttle
control is at the "OFF" position.
4. Connect the flight battery to the speed controller.
5. Check the direction of rotation of the motor: it should
spin clockwise when viewed from the tail, looking
forward. If this is not the case, disconnect the flight
battery and swap over any two of the three motor wires.
7. PERMAX
MOTOR
Type:
#
RPM / V:
Cell count, NiXX / LiPo:
Efficient operating current:
Max. current for 15 sec.:
Shaft Ø:
Diameter:
Length:
Weight:
Max. output:
Max. case temperature:
Mounting:
You will find comprehensive operating instructions for the
PERMAX BL-O 3516-0850 at www.multiplex-rc.de
DOWNLOADS
INSTRUCTIONS.
P
S
"S
OWER
ET
OLIUS
P
S
"S
OWER
ET
OLIUS
-
SPECIFICATION
PERMAX BL-O 3516-0850
33 3231
850
6 - 12 / 2S - 4S
20 A - 28 A
35 A
5 mm
36 mm
37 mm
130 g
350 W
65° C
25 mm / 4 x M3
Page 1/2
"
"
