Installations- och bruksanvisning HELO Roxx Pure
2.18
Aggregat
Adapterkretskort
OLEA 99
Aggregat
Adapterkretskort
OLEA 99
Sensor OLET 31
Silikon 4 x 0,25 mm²
Bild 9 Principskiss
Principskiss när styrcentral Pure
1 = Blå
2 = Vit
3 = Röd
4 = Gul
RJ10 Mellankaabel
Aggregat
Sensor OLET 31
Styrcentral
Pure
Dörrkontakt
Styrcentral
Pure
OBS!
För utförligare
installationsanvisningar
se styrcentralens
bruksanvisning
Inneffekt
230V – 240V 1N~/ 2~
230V 3~
400V – 415V 3N~
13
Ändstopp,
retur,
bekräftelse
.
