INSTALLATION GUIDE

It is good practice to plug in all the equipments before power on.
A/ Connections :
 For the first time, plug IMV600 directly to your computer using the RJ45 port (LAN on the rear panel).
 If you want to use input / output remote control loops, connect the 25-point GPO socket of
your IMV600 to your external devices.
If not, do not connect anything.
B/ Starting:
 Stand alone:
IMV600 features a web server allowing to control from you favorite web browser. Open your
browser, enter IMV600 IP address into the address window.
Default factory IP address is :
Http://
You can now view the web pages, which will allow you to configure the equipment, including
its network settings.
Attention, in case of difficulties, follows the procedure in "technical tools" annex
 Use on a net:
Connect IMV600 to the net using the RJ45 connector.
Attention: To work properly the IMV600 IP address should be unique on the network, and in the
available IP range. Should the PC or routeur net differ from IMV600, first modify PC or routeur
to the same net as IMV600, then set IMV600 IP address as described in "technical tools" annex.
Rami
IMV600
GPI
Made in France (Fr)
100 to 250V 12W T 1A L LAN GPO
RJ 45
192.168.0.60
192.168.0.60
MIC 6 MIC 5 MIC 4
PUSH PUSH
OUT IN OUT IN OUT IN
to external remote controls
.
30
MIC 3 MIC 2 MIC 1
PUSH PUSH PUSH
OUT IN OUT IN OUT
IMV600/
.
PUSH
IN
IMV600
