Nr
Serial nr
Description
1
BC351-801-003
Front foot tube end cap (L)
2
BC351-801-004
Front foot tube end cap (R)
3
BE680-881-004
Transportation wheel
4
BC351-341-004
Wheel axle
5
BC351-341-000
Front foot tube assembly
6
0116-008-05
Flat washer
7
0113-208-16L
Hex screw
8
0114-742-25X
Cross screws
9
/
Computer
10
RC319-303-001
Computer mount
11
/
Cross screws
12
RC319-561-002
Computer angle shifter
13
RC319-561-003
Computer mount sleeve
14
G601-1002-004PK
Fixing nut
15
/
Computer wiring
16
/
Motor
17
0113-105-151
Cross screws
18
RM319-601-001
Motor pulling cable
19
/
Power cable
20
/
Adapter
21
/
Sensor
22
/
Magnet
23
RM319-881-003
Rubber plug
24
0110-706-02
Lock nut
25
RM319-881-004
Strap guide bushing
26
RM319-561-003
Hex Bolt 0111-006-701
27
RM319-200-001
Frame
28
0111-008-728
Hex bolt
29
0171-608-03
Bearing
30
RM620-881-008
Strap roller 1
31
0110-708-02
Lock nut
32
0240-025-19
Inner end cap
33
RM315-861-001PK
Handlebar grip
34
RM315-321-001
Handlebar tube
35
RM315-881-001
Nylon strap
36
0110-410-02
Hex frange nut
37
BC12-011-90
Locking bolt
38
BC12-011-92
U shape stopper
39
0116-306-02
Spring washer
40
0110-006-12
Hex nut
41
0110-010-12
Hex nut
42
0114-142-15X
Cross screws
43
RM315-881-002
Spining wheel cap
44
RM315-561-004
Volute spring
45
/
Spin wheel assembly
46
0113-004-098
Cross screw
47
0110-410-06
Hex frange nut
48
CW-D03-000
Flywheel
49
0113-106-152
Cross screws
50
BE196-561-306
Magnets bracket
51
/
Magnet assembly
52
0161-001-103
Spring
Qty
Nr
Serial nr
Description
1
53
0140-206-240
Belt
1
54L
RM319-801-001
Left cover
2
54R
RM319-801-002
Right cover
2
55
0114-142-191
Cross screws
1
56
0116-208-05
Flat washer
14
57
RM319-881-001
Pedal
20
58
RM610-820-001
Velcro strap
8
59
RM610-881-007
Bushing
1
60
RM319-561-001
Pedal shift
1
61
RM319-561-002
Pedal axle
4
62
AB930-561-018
Bushing
1
63
BC770-801-011
Sensor bracket
2
64
0114-142-11
Cross screws
2
65
RM610-881-101
Seat cushion
1
66
RM319-261-001
Aluminum rail
1
67
RM319-881-002
Rail end cap
4
68
RM319-400-001PK
PU seat
1
69
RM319-300-001
Seat U-bracket assembly
1
70
RM319-561-004
Grooved axle
1
71
RM610-500-001
Roller
1
72
RM319-561-005
Spacer
1
73
RM610-561-009
Grooved bolt
1
74
RC319-300-001
Rear frame support tube
1
75
BC351-801-005
Rear foot tube end cap
1
76
B470-380-002
Feet
1
77
BC351-342-000
Rear foot tube assembly
1
78
M310-881-003
Wire clip cap
2
79
0116-206-02
Flat washer
4
80
0111-106-202
Hexagon screw
2
81
0116-210-52
Flat washer
2
82
0113-105-058
Cross screws
2
83
0116-308-005
Spring washer
2
84
0114-142-088
Cross screws
1
1
2
2
2
2
2
2
3
1
1
1
2
2
1
2
1
1
1
Qty
1
1
1
7
2
2
2
2
1
1
2
1
2
4
1
1
1
1
4
4
4
4
1
2
2
1
1
2
1
4
1
8
8
