Fitting or Changing the
Cut-off Wheel

Clamping the Workpiece

Positioning the Cutting Table

12
Discotom-50
Instruction Manual
The spindle of Discotom-50 is left-hand threaded.
If Discotom-50 has been used for manual cutting, secure the
cut-off wheel with the locking handle on the right hand side of
the machine before changing the cut-off wheel.
Press and hold down the black locking knob on the right-hand
side of the cut-off wheel, turning the cut-off wheel until the
spindle lock clicks.
Remove the nut with a fork spanner. Remove the flange,
cardboard washers and the old cut-off wheel.
Mount the new cut-off wheel.
Conventional cut-off wheels based on Al
between two cardboard washers, to protect the cut-off wheel.
For maximum precision with diamond or CBN cut-off wheels, do not use
Mount the flange and the nut. Tighten carefully and release
the locking knob.
Clamp the workpiece with the clamping device of your choice
e.g. a quick clamping device. Place the workpiece between the
clamp and the back stop.
Push the clamp towards the workpiece and lock the clamp on
the quick-clamping device.
Generally, it is recommended to clamp the workpiece as far back
in the cutting chamber as possible.
Prior to cutting, ensure that the workpiece is held firmly in place by a
Prior to cutting, the cutting table is positioned using the
v
FORWARDS and BACKWARDS
IMPORTANT
IMPORTANT
O /SiC abrasives should be placed
2 3
cardboard washers.
IMPORTANT
clamping device.
V
keys.
