Installation Diagram

Floor Installation (Front Projection)

Wall
*
Adjuster not stretched, and the V Keystone function has been done.
This section describes the examples of installing the projector on a desk, etc.
The alphabetical letters in the illustration indicate the distances below.
a: distance between the screen and the center of the lens
b: distance between the floor and the center of the lens
c: distance between the floor and the bottom of the adjusters of the projector
x: distance between the floor and the center of the screen (free)
56
GB
Center of the
screen
Distance between the front of the cabinet and
the center of the lens
Foremost part Front of the lens
of the cabinet
14.6 (
Floor
19
/ )
32
Center of the lens
Unit: mm (inches)
