14. Parts list
Fig.1 DRIVE UNIT TR2350S (S/N 90200101 and up)
Key# Part Number
1 848-J8S-5820 PIPE COMP.
2 T3400-12130 • SEAL
3 3520-12213 SHAFT
4 848-JC0-6100 GEARCASE ASSY
5 6440-13122 • GEARCASE
6 04065-02612 • SNAP RING
7 3565-13130 • SEAL
8 T3002-13260 • NUT
9 848-JC0-61D0 • PINION
10 T3300-13531 • BEARING
11 T3403- 13530 • BEARING (0600000609)
12 T3300-13330 • SNAP RING
13 04065-02412 • RING (0243224120)
14 T4950-52500 • BOLT TORX, 5x25
15 6440-13242 • HOLDER (A)
16 3199-13350 • FITTING (2087061640)
17 01641-20608 • WASHER
18 T4950-51200 • BOLT TORX, 5x12
20 848-8R4-0600 GRIP ASSY
21 848-BRA-0391 • BODY-R
22 848-8RB-0391 • BODY-L
23 848-8RC-0600 • LEVER, THROTTLE
24 848-8RJ-0600 • SPRING, THROTTLE
25 848-8RD-0600 • LEVER, SAFETY
26 848-JL2-33F3 • SPRING
27 848-8RE-0600 • LEVER, JOINT
28 T4506-52110 • SWITCH
29 848-824-1600 • SCREW
30 848-8P4-0550 • CABLE COMP.
31 848-8M1-0820 • CORD COMP.
32 T3003-14510 • TUBE
33 848-8RH-0421 • BAND
35 4820-13180 • BOLT
36 848-860-5000 • NUT
42 T3300-17202 HANGER COMP.
43 848-805-2000 SCREW TORX, 5x20
44 848-J7G-90R0 LABEL, NAME
45 848-8X1-0040 LABEL, CAUTION
46 T3195-14002 HANDLE ASSY
47 T4960-53030 • SCREW TORX, 5x30
48 848-J6M-6600 GUARD ASSY
49 T3338-24100 • GUARD ASSY
50 6041-24140 • • BLADE
51 0263-90516 • • SCREW
52 3320-15310 • • NUT
53 3520-24120 • CLAMP
Description Q'ty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
4
1
2
1
2
2
2
1
1
1
1
1
4
1
1
1
2
2
1
Key# Part Number
54 T4950-63000 • BOLT TORX
55 PT104 Plus TAP HEAD COMP.
56 848-BU3-69M4 • CASE
57 T3189-15191 • EYELET
58 T3189-15132 • COVER
59 T3189-15142 • CORD HOLDER
60 T3189-15160 • SPRING
61 848-BU3-69S0 • CORD
62 848-8U0-0140 TOOL-SET
63 3540-91110 • BAR
64 848-8U1-0050 • SOCKET
65 T3195-91110 BAG
66 848-A56-92C0 GOGGLE
OPTIONAL BLADE & ACCESSORIES
101 5764-24000 GUARD ASSY
102 5766-24110 • GUARD
103 3250-24120 • BRACKET
104 0225-10620 • BOLT
105 0263-30614 • SCREW
106 0280-10605 • NUT
107 3540-13283 COVER
108 6367-14200 J-HANDLE
109 3583-14101 BRACKET ASSY
110 848-J82-3610 STRAP ASSY
121 SST229 9" 22-tooth
122 SST249 9" 24-tooth
123 SGB088 8" 8-tooth
124 SGB089 9" 8-tooth
125 SGB048 8" 4-tooth
126 SGB049 9" 4-tooth
TR2350S
Description Q'ty
2
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
2
4
4
1
1
1
1
1
1
1
1
1
1
P/L-3
