Operation; Transport; Maintenance/Cleaning - Bosch RIDE+ Performance Line Gen.2 Manuel Du Propriétaire

English–9
After locking, always remove the key 5 from the lock 6. This
prevents the key from falling out and the battery pack from
being removed by unauthorized persons when the eBike is
parked.
To remove the standard battery pack 8, switch it off and
unlock the lock with the key 5. Tilt the battery pack out of
the upper holder 7 and pull it out of the lower holder 9.
To remove the rack-type battery pack 2, switch it off and
unlock the lock with the key 5. Pull the battery pack out of
the holder 1.

Operation

Initial Operation
 Use only original Bosch battery packs approved for
your eBike by the manufacturer and purchased from
a trusted source. Use of non-approved or counterfeit
battery packs can lead to death or serious injury.
Switching On and Off
Switching the battery pack on is one of the ways of starting
the eBike system. Read and follow the operating instruc-
tions for the drive unit and the on-board computer.
Before switching on the battery pack or the eBike system,
check that the lock 6 is locked.
To switch on the battery pack, press the On/Off button 4.
The LEDs for indicator 3 light up and, at the same time,
indicate the charge condition.
 Always check that the battery pack is locked in
place. To do this, pull on the battery pack handle (after
the key has been removed).
Note: When the battery pack capacity is below 5 %, none of
the LEDs for charge-control indicator 3 will light up. Only
the on-board computer will indicate if the eBike system is
switched on.
To switch off the battery pack, press the On/Off button 4
again. The LEDs for indicator 3 go out. This also switches
off the eBike system.
When no power output from the eBike drive unit is request-
ed for approx. 10 minutes (e. g., because the eBike is
parked) and no button for the drive on-board computer or
operating unit is pressed, then the eBike system, and thus
the battery pack, automatically switches off to save energy.
The battery pack is protected against deep discharging,
overcharging, overheating and short-circuiting by the
"Electronic Cell Protection (ECP)". In case of hazardous
situations, a protective circuit automatically switches off
the battery pack.
0 275 U07 XPX | (8.5.17)
When a defect in the battery pack is de-
tected, two LEDs for the charge-control
indicator 3 flash. In this case, please
contact an authorized Bosch eBike
dealer.

Transport

WARNING
 Always remove the battery pack from the bicycle be-
fore transporting the bicycle on a vehicle bike rack.
Failure to remove the battery pack when using a vehicle
bike rack can lead to death or serious injury. The battery
may detach during transport and cause an accident to
following vehicles.
 Always use an approved and compatible bicycle rack
when transporting your eBike. The Bosch Drive Sys-
tem adds weight to the bicycle. Refer to your bicycle
rack manual to be sure your eBike is compatible. Over-
loading a bike rack can result in death or serious injury.
 Use proper lifting techniques because electric bikes
are generally heavier than bicycles.
Ship batteries only when the housings are undamaged.
Tape or mask off open contacts and pack up the battery in
such a way that it cannot move around in the packaging.
Notify your parcel service that the package contains
dangerous goods. Please also follow possibly more de-
tailed national regulations. Always check the state and
federal regulations before attempting to ship your battery.
In case of questions concerning transport of the battery
packs, please contact an authorized Bosch eBike dealer.
Bosch eBike dealers can also provide suitable transport
packaging.

Maintenance/Cleaning

WARNING
 Do not open any of the components. Service should
only be carried out at an authorized Bosch eBike
dealer. Failure to follow the above warning may result in
death or serious injury. Refer to your bicycle manual or
component manual for all non-Bosch Drive System com-
ponents.
 Always remove the battery pack before performing
any bicycle inspection, maintenance or repair.
Failure to remove the battery pack before performing
bicycle inspection, maintenance or repair can lead to
serious injury.
160
Bosch eBike Systems
