When the capacity of the battery pack is below 5 %, all LEDs
for the charge-control indicator 3 on the battery pack turn
off; however, the on-board computer does provide an addi-
tional indicator function.
After charging, disconnect the battery from the charger and
the charger from the network.
Using Two Battery Packs for One eBike
(optional)
An eBike can also be equipped with two battery packs by
the manufacturer. In this case, one of the charge sockets is
not accessible or is sealed by the eBike manufacturer with
a sealing cap. Charge the battery packs only at the
accessible charge socket.
 Never open charge sockets that have been sealed by
the manufacturer. Charging at a previously sealed
charge socket can lead to irreparable damage.
If you have an eBike that is designed for two battery packs
and you want to use it with only one battery pack, cover off
the contacts of the unused socket using the cover lid 10
provided because otherwise the open contacts pose a risk
of short-circuiting.
Charging with Two Battery Packs Inserted
If two battery packs are mounted on one eBike, both bat-
tery packs can be charged using the unsealed connection.
The charging process will charge both battery packs alter-
nately, automatically switching between both battery
packs numerous times. The charging times add up.
Both battery packs are also discharged alternately during
operation.
If you take the battery packs out of the holders, you can
charge each battery pack individually.
Charging with One Battery Pack Inserted
If only one battery pack is inserted, then you can charge
only the battery pack that has the accessible charge socket
on the bike. You can charge the battery pack with the
sealed charge socket only when you take the battery pack
out of the holder.
Bosch eBike Systems
Inserting and removing the battery pack
6
5
8
9
1
6
5
 Always switch off the battery pack and the eBike
system when you insert the battery pack into the
holder or when you take it out of the holder.
In order for the battery pack to be inserted, the key 5 must
be inserted into the lock 6 and the lock must be unlocked.
To insert the standard battery pack 8, place it with the
contacts on the lower holder 9 on the eBike (the battery
pack can be inclined up to 7° to the frame). Tilt it into the
upper holder 7 until it engages.
To insert the rack-type battery pack 2, slide it with the
contacts facing ahead until it engages in the holder 1 of the
rear rack/carrier.
 Always check that the battery pack is locked in
place. To do this, pull on the battery pack handle (after
the key has been removed).
Check if the battery pack is tightly seated. Always lock the
battery pack with lock 6; otherwise the lock can open and
the battery pack could fall out of the holder.
159
English–8
7
10
10
0 275 U07 XPX | (8.5.17)
2
