Nordelettronica KIT NE129 Instructions D'emploi page 9

CONTROL PANEL NE102
CONTROLS:
TEST:
DISPLAY:
When the panel is on stand-by the display shows the date, time, internal and external
12/06/01 14:52
temperatures. If the power is on or the recycle tank (S2) is full or a fuse on the distribution
IN:25°C OUT:30°C
panel NE129 has burnt out, the date disappears and is replaced by the words 230V, FUSE
230V FULL 14:52
and flashing FULL. If there are no temperature probes the words 230V and FULL are
IN:25°C OUT:30°C
shown on the second line.
12/06/01 14:52
230V FUSE
Press the TEST key once to activate battery voltage reading for 20 sec.
B1:12.4V If the battery voltage is below 11V and 10V respectively for B1 and B2 the indicator flashes
B2:12.7V
to warn the user that the batteries are flat.
If with the engine running there is a difference between the two batteries of more than or the
B1:12.4V
same as 0.4V the B2 indicator flashes to warn the user that the alternator is not charging the
B2: 9.8V
service battery (it is advisable to take the vehicle to a service center to check the electrical
B1:12.4V
system).
B2:12.0V
If there is an "amperometer" accessory the display will also show the charge or discharge
B1:12.4V
current for the service battery (B2).
B2:12.7V -25.8A
Press the test push button while reading the battery voltage to display the reading for the
drinking water tank (S1) level and the recycle tank S2 level. The display will show the
S1: 2/3
S2: 1/3 respective levels.
If there is a "litre probe"(mod. NE131) accessory measurement is not by level but linear with
S1: 125 LITRES
an indication of the litres.
S2: 0
REGULATING THE CLOCK AND ALARM CLOCK:
Hold down the TEST key for 5 sec. to enter the clock and alarm clock regulation menu. The
initial display will show the day flashing. Use the push buttons (1) and (2) to increase or
decrease the value. Press the TEST key repeatedly to regulate the month, year, hour, minutes
and activate (YES) or deactivate (NO) the alarm clock with its relative time. The alarm will
sound for 30 sec.; press any key to turn it off. When the alarm is on (YES) the # symbol next
to the hour indicator will flash.
MANAGING FLAT BATTERIES
Whenever battery B1 drops below 11V
show the battery voltage window.
Whenever battery B2 drops below 10V
battery voltage window. One minute later the NE129 distribution panel disables the various power supplies for
lights and pump. To reactivate the relays press the corresponding key. However, if the battery remains below
10V it will deactivate again after one minute.
DIMENSIONS:
(L x H) 250 x 78 mm
- (1) Push button with warning light to turn the internal lights on and off.
- (2) Push button with warning light to turn the external light on and off.
(The external light goes off automatically with the engine running.
The internal light switch also acts as a master switch for the external light).
- (3) Push button with warning light to turn the pump on and off.
- (4) Push button to carry out the tank level and battery voltage test.
Push once to activate the following for 20 sec. :
- car battery (B1) reading
- service battery (B2) reading
- optional: charge or discharge current reading for B2
Push a second time to activate the following for a further 20 sec. :
- tank level reading
- (5) Alphanumeric display 16x2 retro-illuminated characters:
an intermittent buzzer will sound for 5 sec. and for 1 min. the display will
an intermittent buzzer is generated for 5 sec. and the display shows the
Fig. 2
12/07/01 14:52
ALARM YES 6:30
12/06/01 #14:52
IN:25°C OUT:30°C
