Connect Drain Hose - Maytag Performance Série Instructions D'installation

3.
Remove transport bolts from
washer
Loosen bolts with a 13 mm (1/2") wrench.
Slide each bolt and spacer to center of hole. Pull bolts and
plastic spacers from back of washer. Save transport bolts
and spacers. Contact a qualified servicer if washer is to be
transported.
4.
Cover bolt holes with transport
bolt hole plugs
Close bolt holes on cabinet back with transport bolt hole plugs
included with washer parts.
5.
Remove power cord
Pull power cord through opening in rear panel and close
holes (2) with attached white plastic cap.
NOTE:
If washer is transported at a later date, call a certified
technician to properly set up washer for relocation, to avoid
suspension and structural damage.
6
6.
Place power cord over top
Gently place power cord over top of washer to allow free
access to back of washer.

CONNECT DRAIN HOSE

7.
Attach drain hose to drain port
Squeeze hose clamp tabs with pliers and slide over end of
drain hose. Slide drain hose onto washer elbow connector
and secure with clamp.
For a laundry tub or standpipe drain, go to step 8.
You may need additional parts with separate directions.
See Floor drain system under "Alternative Parts".
