en Product information
5 Product information
5.1 Type key
Example: Modbus RTU CIF module
CIF module
Modbus RTU
Table 2: Type key
5.2 Technical data
Technical data
General data
Terminal diameter (finely stranded without end
sleeves)
Electric circuit
Ethernet interface according to IEEE 802.3
Interface
Interface type
Connection type
Connection type
Cable length
CAN interface according to ISO 11898-2
Cable length
Termination resistor
RS485 interface as per EIA/TIA (RS) 485-A
*
Load (unit load)
Input voltage
Termination resistor
TP/FT-10 interface
Cable type
18
"Communication Interface" module
Model/function identifier:
Modbus RTU = RS485 interface, Modbus RTU pro-
tocol
BACnet MS/TP = RS485 interface, BACnet MS/TP
protocol
²
1.5 mm (max.)
SELV, galvanically isolated
2 (integrated switch)
Auto MDI-X
10BASE-T, 100BASE-TX (half/full duplex, auto-
negotiation)
RJ45 bush (shielded)
100 m (max.)
200 m (max.)
120 Ω (integrated, switchable)
1/8 unit load
Max. 12 V (differential A-B)
120 Ω (integrated, switchable)
J-Y(St) Y 1 x 2 x 0,8 mm / CAT 5 AWG 22
