Ridder tube motors.
RIDDER TUBE MOTORS ARE SPECIALLY DEVELOPED FOR ROLL SCREEN SYSTEMS.
OTHER APPLICATIONS ARE ONLY PERMITTED AFTER RECEIVING SPECIFIC APPROVAL
The Ridder tube motor is a maintenance free, low noise system for driving roll screen systems
with a winding tube of ø50 mm. The built-in limit switch has a range of up to 38 rotations.
The main roll screen applications are:
- Roof screen with a minimum pitch of 20°
- Side screens
Tube motor technical data.
M
n
P
U
~
I
p
RB50-3.5\230
Tube motor accessories.
- Tube motor guiding unit with guiding profile and mounting bow guiding profile
- Cable thread with mounting set
- SH40 square headed gearbox
- RMC50 tube motor control unit with run time protection
- Tube motor testing switch
Fig. 1 Fig. 1
Explanation of the names in main groups with their parts.
1. [a b c]
2.
3.
4.
5.
6. [a b c d e] Mounting set cable thread
RB50 / 0505
Ridder Drive Systems BV HARDERWIJK NEDERLAND Tel.: +31 (0)341 416 8 54
FROM RIDDER AANDRIJFSYSTEMEN BV.
couple output
number of revolutions
supplied capacity
mains voltage
phase
current
frequency
voltage
number of revolutions per minute
Nm
Tube motor
Tube motor guiding unit
Guiding profile
Mounting bow guiding profile
Cable thread
IP protection class
KB nominal run time
Tth run-time thermal cut-off
BES limit switch range
L tube motor length
m tube motor weight
1a. motor 1b. split pin 1c. hexagonal key
6a. square plate 6b. ty-rap 6c. straight plate
6d.blind rivet 6e. end connector
