11. SPECIFICATIONS
Booster
Internal battery type ....................................................Maintenance-free AGM lead-acid
Nominal voltage .......................................................................................... 12V/24V DC
Capacity ........................................................................................................... 2 x 50 Ah
Peak amps, 12V.................................................................................................... 10000
Peak amps, 24V...................................................................................................... 5000
Cranking amps, 12V ............................................................................................... 1050
Cranking amps, 24V ................................................................................................. 850
Cold cranking amps, 12V .......................................................................................... 780
Cold cranking amps, 24V .......................................................................................... 530
Jumper cables.........................................................................................70 mm
Dimensions ......................................................................... 19.68 x 21.26 x 43.3 inches
Weight ................................................................................................152.12 lbs. (69 kg)
Charger
Input Voltage. .............................................................................120V AC @ 60Hz, 2.2A
Output Voltage ..........................................................................................................12V
Output Current Rating ..................................................................................... 8A @ 12V

12. REPLACEMENT PARTS

Booster
Meter ......................................................................................................... 5399200032Z
Push button ............................................................................................... 0499000177Z
Internal battery (12V, 50Ah) ...................................................................... 5799000043Z
Battery clamps .......................................................................................... 2299002913Z
Fuse (AMG heavy-duty, 500A) .................................................................. 3999002114Z
Wheel (front) ............................................................................................. 4999001284Z
Wheel (side) .............................................................................................. 4999001285Z
Charger
SC3DSR charger ...................................................................................... 2299002873Z
Plug kit. ..................................................................................................... 2299002914Z
13. TROUBLESHOOTING
Booster
PROBLEM
The booster does not recharge. The AC outlet is dead.
REASON
Poor electrical connection.
The booster is not connected
correctly.
16A 12V accessory plug breaker
is tripped.
The battery is bad.
• 9 •
2
SOLUTION
Check for open fuse or circuit
breaker supplying AC outlet.
Check power cord and extension
cord for a loose fitting plug.
Verify the connections from the
booster's charging plug to the
battery.
Press the red button, to
manually reset the breaker
on the charge port.
Replace the battery.
, 82.68"
