afx light SPOT120LED Manuel D'utilisation page 7

SLAVE M ODE
Up-­‐to 3 2 u nits c an b e d aisy c hained t ogether w ith o ne s ingle u nit a cting a s M aster a nd a ll o ther l inked u nits a cting a s
Slaves. S lave u nits w ill a ll r un i n s ync w ith t he m aster u nit w ithout t he n eed f or a n a dditional c ontroller. C onnections
can b e m ade u sing s tandard D MX c ontrol c ables w ith M aster u nit r unning i n A uto R un o r S ound A ctivated M odes
and p laced a t t he b eginning o f t he c hain
Selection o f S lave M ode
Press t he " MENU" b utton a nd c hoose " RUN". W hen t he " ENTER" b utton i s p ressed, t he L ED d isplay c hanges t o
"SLAVE" a nd t he u nit w ill b e s laved t o c ontrol s ignals c oming f rom a M aster u nit
DMX M ODES
Setting D MX A ddresses
Use t he " MENU" b utton t o d isplay " GENERAL". P ress E NTER a nd u se U p a nd D own b uttons t o s elect " A DDRESS"
then p ress E NTER. U se " UP" a nd " DOWN" b uttons a llows i ndividual D MX a ddresses t o b e s et f rom " d001" t o " d512"
DMX T ABLE
16 D MX C HANNEL M ODE
CHANNELS FUNCTION
1
2 Pan 16Bit
3
4 Tilt 16Bit
5 Pan & Tilt speed
6 Dimmer
7 Strobe
8 Color wheel
9 Color offset
10 Focus
Rotating gobo
11
wheel
©Copyright L OTRONIC 2 015
DMX
Pan 000-255
000-255
Tilt 000-255
000-255
000-255
000-255
000-255
000-255
000-255
000-255
000-255
Functions
0-540
Pan fine
0-270
Tilt fine
Slow-fast
From dark to bright
0-5 No function
6-249 Strobe effect ( from slow to fast )
250-255 No function
0-19 Open / white
20-39 Dark blue
40-59 Orange
60-79 Light green
80-99 Light blue
100-119 Red
120-139 Green
140-159 Pink
160-179 Yellow
180-219 Clockwise rainbow effect ( from fast to slow )
220-255 Unclockwise rainbow effect ( from slow to fast )
0-100% step by 1/256
From close to far
0-19 Open
20-39 Gobo1
40-59 Gobo 2
60-79 Gobo 3
80-99 Gobo 4
100-119 Gobo 5
120-139 Gobo 6
140-159 Gobo 7
160-199 Clockwise gobo change ( from fast to slow )
200-255 Unclockwise gobo change ( from slow to fast )
SPOT120LED Page 7
