Clean the empty enclosure in regular intervals, in particular contaminated fittings, to avoid sluggishness and malfunctions. If necessary, fittings must be
treated with suitable lubricants.
Exchange damaged parts and use original häwa parts only.
When purchasing spare parts, please state the enclosure product code and your order number to ensure identification – see inside of door.
You will find a list of spare parts on page 17.
Hygiene
The plant maintenance plan must include measures which ensure that the required hygiene status is maintained.
7.3 Instructions for the Exchange or Replacement of Individual Components
a) Exchanging a hygiene seal
(see 10. Spare Parts)
Place sealing frame onto
groove of door.
Press complete seal into
the groove up to door corner.
b) Exchanging a lock
(see 10. Spare parts)
Information:
The quarter turn latch locks are partly assembled. The locking pin including O-ring (blue) and spring washer (DIN 137, Form B) is inserted into the turn lock
casing and fastened by means of a hex socket screw.
When mounting it into the door opening, attention must be paid to
- proper fitting of the blue seal on the turn lock casing,
14
Press seal into groove at the
four corners of the door.
Correct
Seal covers the panel edge.
Press seal into sealing groove
approx. every 100 – 150 mm.
Attention
When installing the seal, do not pull it
out of the corners.
