Quick Start
Remove Stand for Mounting
The stand can be removed in order to mount the monitor using an alternate, VESA
approved, mounting method.
1.Disconnect all cables.
2. With one hand, grip the top of the display by the handle using the other
hand to grip the bottom. Raise the monitor up to the highest position
(see Raising and Lowering Monitor Screen page 5).
3. Place monitor face down on a nonabrasive surface (Figure S.1).
4. Place one hand around the base and one hand on the Quick Release Lever.
Move the Quick Release Lever in the direction indicated by the arrows
(Figure S.2) .
5. Lift up the bottom of the stand to unhook it from the monitor (Figure S.3).
The monitor can now be mounted using and alternate method.
Reverse the process to reattach stand.
NOTE: Use only VESA-compatible alternative mounting method. (100mm pitch)
NOTE: Handle with care when removing monitor stand.
(Figure S.1)
(Figure S.3)
– continued
7
1. Pull lever towards stand.
2. Slide lever to the right.
(Figure S.2)
UP
1
SLIDE
2
