Quick Start
Highest
Stand
Position
power card
(DC out for optional NEC products
such as the Soundbar attachment. Do
not use thisconnector unless specified.)
6. Hold all of the cables firmly and place the cable cover onto the
stand (Figure 7).
7. Slide the Cable Cover back into its correct position (Figure 8).
Connect the power cord to power outlet.
NOTE: Please refer to the Recommended Use section of this manual for proper
selection of power cord.
8. The vacation switch on the back side of the monitor near the AC inlet must be in the
ON position for the monitor to function (Figure 9).
Turn on the monitor using the front power button, then turn on the computer.
NOTE: The Vacation Switch is a true on/off switch. If this
switch is in the OFF position, the monitor cannot be
turned on using the front button.
DO NOT turn the vacation switch ON/OFF repeatedly.
9. For Analog input only: Upon initial setup, the No-Touch Auto Adjust feature auto-
matically adjusts the monitor to the optimal settings that are needed for most signal
timings.
For further adjustments, refer to the Controls section of this User's Manual for a full
description of the OSM controls.
For download information on the Windows® 95/98/Me/2000/XP INF file for
your monitor, visit www.necdisplay.com/support.
NOTE: If you have any problems, please refer to the Troubleshooting section of this
User's Manual.
– continued
30 Tilt
DVI-I
D-SUB
Figure 4
4
Figure 5
