Flexible Arm Installation

This LCD monitor is designed for use with a flexible arm.
To mount the monitor to a flexible arm:
1. Remove the stand (see Remove Monitor Stand for Mounting page 7).
2. Use the 4 screws that are included to attach the arm to the monitor
(Figure F.1).
100mm
CAUTION: Use ONLY the 4 screws that are included when mounting to avoid
damaging the monitor and the stand or arm. For safety requirements,
the monitor must be mounted to an arm which guaranties the necessary
stability under consideration of the weight of the monitor. The LCD moni-
tor should only be used with an approved arm (e.g. GS mark).
– continued
100mm
(Figure F.1)
