English

EXT REM IN Jack -

This 3.5mm mini-jack receives command codes from industry-standard infrared
receivers via hard-wired connections. This feature could prove useful when
the unit is installed in a cabinet and the front-panel sensor is blocked. Consult
your authorized Rotel dealer for information on these external repeaters and
the proper wiring of a jack to fit the mini-jack receptacle.

Computer I/O Connector =

The RC-1570 can be controlled via RS232 for integration with automation
systems. The COMPUTER I/O input accepts a standard straight DB-9 Male-
to-Female cable.
For additional information on the connections, software, and operating codes
for computer control of the RC-1570, contact your authorized Rotel dealer.
PC-USB Input y
See Figure 5
Connect this input using the supplied USB cable to the PC-USB socket of
your computer.
The RC-1570 supports both USB Audio Class 1.0 and USB Audio Class
2.0 modes. Windows computers do not require installation of a driver for
USB Audio Class 1.0 and support playback of audio up to 96kHz sampling
rates. The Factory Default setting is USB Audio Class 1.0.
To take advantage of USB Audio Class 2.0 audio playback supporting
up to 192kHz sampling rates you will need to install the Windows driver
supplied on CD included with the RC-1570. You will also need to switch
the RC-1570 to USB Audio Class 2.0 playback mode with the following:
• Press MENU on the front panel until "PC-USB AUDIO CLASS" appears
on the display.
• Select "2.0" using the "-" key then press "ENTER".
• Power cycle the RC-1570 and reboot your PC after changing the USB
Audio mode to ensure both units are properly configured.
Many audio playback applications do not support 192kHz sampling rate.
Please confirm your audio player supports 192kHz audio and you have
192kHz audio files to properly playback this sample rate. Also, you may
need to configure the audio driver in your PC to output 192kHz or your
computer may "down sample" to a lower audio sample rate. For more
information please refer to your audio player or operating system information.
NOTE: USB Audio Class 2.0 required installation of the Windows PC
driver on the CD ROM included with the RC-1570.
NOTE: MAC computers do not require a driver to support PC-USB
1.0 or 2.0 audio.
NOTE: Upon successful installation of the driver, you may need to select
the ROTEL audio driver from the audio/speaker setup of your computer.

Settings Menu

You can access the settings menu from the front panel by pressing the MENU
8 button or the MENU D button on the remote control. You can change
the value of the selected option by pressing the +/- button on the front
E
panel or left/right arrow keys on the remote control. Step through the
sub-menus by pressing the MENU
D
button on the remote control.
• Tone Control: TONE BYPASS ON/OFF, BASS level and TREBLE levels can
be changed to desired settings. Press the ENTER button on the front panel or
the ENT key on the remote control to toggle between the tone setup options.
(For more information on Tone Control refer to the Tone Control Bypass,
Bass and Treble control sections.)
NOTE: These settings are stored permanently even after the RC-1570
is powered off.
• BALANCE: Changes left/right balance (For more information on Balance
sections).
NOTE: This setting is stored permanently even after the RC-1570 is
powered off.
• DIMMER: Dims the display.
NOTE: This setting is stored permanently even after the RC-1570 is
powered off.
• ROTEL LINK RCD: Selects how the CD player is connected to the amplifier,
either CD (analog), COAX1 or COAX2. CD is the factory default.
• POWER ON MAX VOLUME: This sets the maximum volume level when
the unit is turned ON. "45" is the factory default.
NOTE: Power On Max Volume settings do not apply to sources
configured with Fixed Gain.
• AUTO POWER OFF: The RC-1570 can be configured to automatically
power off if unused for a specified period. If no changes are made to the
unit within the specified "Auto Power Off" timer the unit will automatically
go to STANDBY mode. The Auto Power Off timer will be restarted if changes
are made to the volume, source or playback. The default for Auto Power
Off is set to DISABLE.
Valid settings include: DISABLE, 1 HOUR, 2 HOURS, 5 HOURS, 12 HOURS.
• FIXED GAIN: Configures a Fixed Volume level for a specified input. To
enable this feature press the +/- keys to select the desired fixed volume level
for Aux 1, Coax 1, Coax 2, Optical 1, Optical 2, PC-USB or Bluetooth.
When enabled and the input with a Fixed Volume is selected, the Volume
level will immediately be set to the specified level.
Valid settings include: VARIABLE, FIXED 1-95, FIXED MAX.
NOTE: The Volume knob on the front panel and Volume +/- buttons
on the IR remote are disabled when the volume is Fixed. To disable this
feature set the Fixed Volume level to "Variable".
• AUX1 VOL: VARIABLE (disabled) is factory default.
button on the front panel or MENU
8
