Installation

6 Installation
6.1

Installation diagram

Fig. 5: Dispensing valve attached separately
NOTICE!
The dispensing valve is to be fitted as closely as possible to the rotor spray to
exclude errors in dispensing and the dispensing monitoring.
We recommend using the angle bracket available as an accessory.
Fig. 6: Dispensing valve attached using angle bracket
