To Use
12
Removing the Wheels
Press the release button and pull the rear wheel
out of the frame (Figure 12).
Press the release button and pull the front wheel
off of the frame (Figure 12a).
WARNING
13
To Use Restraint System
Place your child in the stroller, with the crotch strap
between the child's legs. Fit clips together. Slide clips
into buckle until you hear a "click" (Figure 13).
Tighten straps snugly around your child (Figure
13a).
To tighten strap, slide buckles down (Figure 13b).
To loosen strap, slide buckles up (Figure 13b).
14
Adjust Restraint Height
The shoulder straps have three height positions
for your growing child. Push each anchor through
the seat back and into the desired slot (Figure 14).
Be sure the anchor lays flat against the seat back.
WARNING
12
• NEVER LEAVE CHILD UNATTENDED.
• AVOID SERIOUS INJURY from falling or sliding out. Always use seat belt. Check
frequently to make sure it is secure. Belts must be threaded exactly as shown.
• Failure to follow these instructions could result in the serious injury or death of your child.
13
14
Anchors
• For proper installation of the restraint system, make sure both anchors lay
flat against the seat back.
• NEVER use stroller without BOTH restraint and crotch straps.
12a
13a
6
TM
13b
