PARTS LIST
No. Description
1 Main frame
2 Knob
3 Cover
4 Foam handle
5 Handlebar
6 Computer
7 Resistance knob
8 Washer
9 Nylon nut
10 Washer
11 Pedal
12 Hex bolt
13 Seat
14 Hex bolt
15 Knob
16 Nylon nut
17 Washer
18 Seat support
19 Hex bolt
20 Tube spacer
21 Pulley
22 Rail
23 Belt
24 Knob rail
25 Hex bolt
26 Phillips screw
27 Knob
28 Rear stabiliser
29 Cover rear stabiliser
30 Bolt
31 Curved washer
32 Cap nut
33 Front stabiliser
34 Cover front stabiliser
35 Washer
36 Sensor wire
37 Phillips screw
38 Square cover
39 Magnet
Attention:
Some of the above mentioned parts have already been assembled to a main body. These are not
delivered separately!
Qty No. Description
1 40 Nut
1 41 Bearing
2 42 Wheel
2 43 Tube spacer
1 44 Connection plate
1 45 Phillips screw
1 46 Computer cable
2 47 Sensor
1 48 Rotation plate
2 49 Washer
2 50 Rotation axle for flywheel
2 51 Tube spacer rotation axle
1 52 Flywheel
1 53 Magnet
1 54 Washer
4 55 Bolt
8 56 Spring washer
1 57 Washer
3 58 Wheel
1 59 Self‐tapping screw
2 60 Left and right cover
1 61 Flange nut
1 62 Hex nut
4 63 Axle flywheel
1 64 Belleville spring
4 65 Axle for Belleville spring
1 66 Collar for axle
1 67 Collar for axle
2 68 Self‐tapping screw
2 69 Cover rotation plate
2 70 Square rubber plate
2 71 Cap nut
1 72 Cover
2 73 Collar for axle
1 74 Tube spacer
1 75 Bearing
2 76 Wrench
1 77 Wrench
1 78 Wrench
20
Qty
1
1
4
2
1
2
1
1
1
1
1
1
1
1
1
4
4
4
2
10
1
2
1
1
1
1
1
1
3
1
1
2
1
4
2
4
1
1
2
