1
ON / OFF
3

Inserting micro-SD card

To insert a micro-SD card, first open
the rubber cover and then insert
the memory card as illustrated. You
cannot record anything without a
storage medium.
!
SD card prerequisite:
microSDHC, class 10, FAT32
5
Main menu
General and measurement-specific settings can be made in the main menu. The menu is controlled with
the four buttons (b, c, f, g).
20
GB
2

Charging the li-ion battery

To charge the Li-Ion battery
pack, plug the supplied
1 sec
power supply/battery
ON
charger into charging
socket „l" and connect
it to an appropriate
power source.
3 sec
OFF
Operation while
charging is possible.
4
Removing / inserting
li-ion battery pack
Open battery compartment (12).
Measure
Emissivity
Palette
Range
Settings
Select Close
