Roxxy
BL-Outrunner
®
New 14-pole, triple ballraced ROXXY® BL D-series outrunner motor.
D-series motors feature a third bearing, known as a thin-ring ball-
race, for improved true-running and precision. This stops the motor
bell from distorting and ensures smoother running. These motors
require no gearbox due to their construction. They are highly effi-
cient, high-torque motors with a wide power band, capable of driving
large propellers.
Typical application
For electric gliders up to about 3200 g
Scale and sport models up to about 2500 g
Aerobatic and 3-D models up to about 1800 g
Installation advice
- Select the fixing screws length so that no damage to the motor
occurs. Use (Loctite 648) thread-lock fluid so that the screws do
not loosen in use. The thread-lock fluid must not get into the ball
bearings.
- Ensure the outrunner bell runs freely.
- Do not use damaged propellers.
- Ensure that neither dirt, water nor metal particles can enter the
inner workings of the motor.
- If the motor runs in the wrong direction, swap two the three power
cables over.
Recommended LiPo batteries
ROXXY
®
Power LiPo-batteries
Specification
D35-50-06 850 Kv No. 31 4995
Voltage
Rotational speed
Load current
Max. load current
Dimensions
Weight approx.
Shaft diameter
D35-50-05 1150 Kv No. 31 4996
Voltage
Rotational speed
Load current
Max. load current
Dimensions
Weight approx.
Shaft diameter
1mm
47mm
!
Safety notes for operating the motor
- Whenever you are installing or otherwise handling the motor or speed control-
ler, be sure to observe the instructions supplied with those units.
- It is also important to study the instructions provided with the LiPo battery
before using them for the first time.
- Whenever you are working on the model - making adjustments, carrying out
maintenance etc. - keep well clear of the rotational plane of the propeller, as
it constitutes an injury hazard. Do not let anybody stand in front of the model
when the engine is running.
www.modellmarkt24.ch
www.modellmarkt24.ch
Roxxy® BL-Outrunner – Bedienungsanleitung,
Operating instructions, Notice d'utilisation –
7-20 Volt / 2-5 LiPo
850 rpm / V
50 A (5 min / 120°C)
65 A (60 secs.)
Ø 35 x 50 mm
149 g
4 mm
7-20 Volt / 2-5 LiPo
1150 rpm / V
38 A (5 min / 120°C)
45 A (60 secs.)
Ø 35 x 50 mm
149 g
4 mm
25 mm
15mm
4mm
D35-50
Suitable Roxxy-BL-controllers
No.
Type
31 8632
950-6
31 8634
960-6
Prop data table No. 31 4995
Voltage
LiPo-cells
Imax (A)
Propeller
(V)
(5 min)
7,0
2
50
17 x 8 APC_E
7,0
2
50
17 x 10 APC_E
10,5
3
50
11 x 10 APC_E
10,5
3
50
12 x 10 APC_E_
10,5
3
50
12 x 10 APC_E
10,5
3
50
13 x 6,5 APC_E
10,5
3
50
13 x 8 APC_E
10,5
3
50
14 x 7 APC_E
10,5
3
50
14 x 8,5 APC_E
14,0
4
50
10 x 8 Aeronaut_E_Prop
14,0
4
50
10 x 10 APC_E
14,0
4
50
11 x 7 APC_E
14,0
4
50
11 x 8,5 APC_E
14,0
4
50
11 x 8 APC_E
14,0
4
50
12 x 6 APC_E
14,0
4
50
13 x 4 APC_E
17,5
5
50
9 x 7,5 APC_E
17,5
5
50
9,5 x 7 Aeronaut_E_Prop
17,5
5
50
10 x 7 Aeronaut_E_Prop
Prop data table No. 31 4996
Voltage
LiPo-cells
Imax (A)
Propeller
(V)
(5 min)
7,0
2
38
10 x 8 Aeronaut_E_Prop
7,0
2
38
10 x 10 APC_E
7,0
2
38
11 x 7 APC_E
7,0
2
38
11 x 8,5 APC_E
7,0
2
38
11 x 8 APC_E
7,0
2
38
12 x 6 APC_E
7,0
2
38
12 x 8 APC_E
7,0
2
38
13 x 4 APC_E
10,5
3
38
8 x 8 APC_E
10,5
3
38
9 x 5 Aeronaut_E_Prop
10,5
3
38
9,5 x 7 Aeronaut_E_Prop
10,5
3
38
10 x 5 APC_E
10,5
3
38
10 x 6 Aeronaut_E_Prop
14,0
4
38
8,5 x 6 Aeronaut_E_Prop
DISPOSAL
This symbol means that it is essential to dispose of electrical and elec-
tronic equipment separately from the domestic refuse when it reaches the
end of its useful life. Take your unwanted equipment to your local com-
munal collection point or recycling centre. This applies to all countries of
the European Union, and to other European countries with separate waste
collection systems.
CE CONFORMITY DECLARATION
This device has been assessed and approved in accordance with European harmonised
directives. This means that you possess a product whose design and construction fulfil
the protective aims of the European Community designed to ensure the safe operation
of equipment.
If required, you can request MULTIPLEX Modellsport GmbH & Co.KG to supply a copy
of the unit's Conformity Declaration. Please contact the company using the contact
details at the foot of the page.
Errors and omissions excepted.
Technical modifications reserved.
Copyright Multiplex Modellsport 2015
Duplication and copying of the text, in whole or in part, is only permitted with the prior written
approval of Multiplex Modellsport GmbH & Co.KG
Multiplex Modellsport GmbH & Co. KG
Westliche Gewerbestr. 1
75015 Bretten
Germany
Multiplex Service: +49 (0) 7252 - 5 80 93 33
www.multiplex-rc.de
No. 31 4995, 31 4996
LiPo cellcount / Load current (A)
2-6S / 50A
2-6S / 60A
Efficiency
Rpm
Load
(%)
current (A)
64%
3.969
36,3
60%
3.686
41,2
71%
6.882
37,7
71%
6.816
38,8
v2
70%
6.661
41,6
72%
7.017
35,3
71%
6.880
37,7
70%
6.664
41,5
69%
6.600
42,7
79%
9.656
34,8
76%
9.265
40,5
78%
9.500
37,1
76%
9.271
40,4
76%
9.227
41,0
76%
9.236
40,9
78%
9.506
37,0
81%
12.371
36,5
82%
12.544
34,1
81%
12.185
39,1
Efficiency
Rpm
Load
(%)
current (A)
75%
6.813
25,6
75%
6.560
30,5
75%
6.788
26,0
75%
6.728
27,2
75%
6.634
29,0
75%
6.683
28,1
74%
6.440
32,8
75%
6.788
26,0
79%
10.353
31,7
79%
10.481
29,6
79%
10.292
32,8
79%
10.392
31,1
79%
10.339
32,0
82%
14.312
30,8
Thrust
(g)
1.692
1.583
1.336
1.304
1.242
1.665
1.911
2.078
1.969
1.621
1.590
2.062
2.156
1.808
2.421
2.612
2.019
1.922
1.654
Thrust
(g)
807
816
1.002
1.049
958
1.204
1.251
1.246
955
1.368
1.294
1.576
1.461
1.462
