warninG
To avoid injury or accident by the chuck key ejecting
forcibly from the chuck when the power is turned "ON",
use only the self-ejecting chuck key supplied with this
drill press. Always recheck and remove the chuck key
before turning the power "ON". Place the chuck key into
its storage holder when not in use.
DrillinG to a spEcific DEptH
Drilling a blind hole (not all the way through workpiece) to
a given depth can be done two ways:
workpiece method
See Figure 27.
1. Mark the depth of the hole on the side of the workpiece.
2. With the switch "OFF", bring the drill bit down until the
tip is even with the mark.
3. Hold the feed handle at this position.
4. Spin the lower nut down to contact the depth stop lug
on the head.
5. Spin the upper nut down and tighten against the lower
nut.
6. The drill bit will now stop after traveling the distance
marked on the workpiece.
Depth scale method
See Figure 28.
notE: With the chuck in the upper position, the tip of the
drill bit must be just slightly above the top of the workpiece.
1. With the switch "OFF", turn the feed handle until the
pointer points to the desired depth on the depth scale
and hold the feed handle in that position.
2. Spin the lower nut down to contact the depth stop lug.
3. Spin the upper nut against the lower stop nut and
tighten.
4. The drill bit will stop after traveling the distance
selected on the depth scale.
Drilling a hole
1. Using a centre punch or a sharp nail, make an
indentation in the workpiece where you want to drill.
2. Turn on the laser guide and align the laser lines with
the indentation.
3. Turn the power switch on and pull down on the feed
handles with only enough effort to allow the drill to cut.
Feeding too rapidly might cause the belt or drill to slip, tear
the workpiece loose, or break the drill bit.
When drilling metal, it will be necessary to lubricate the
tip of the drill bit with metal drilling oil to prevent it from
overheating.
PT
DA
SV
FI
NO
RU
English
PL
CS
HU
RO
LV
LT
for your protEction
To avoid being pulled into the power tool, do not wear
loose clothing, gloves, neckties, or jewellery. Always tie
back long hair.
1. If any part of your drill press is missing, malfunctioning,
damaged or broken, stop operation immediately until
that part is properly repaired or replaced.
2. Never place your fingers in a position where they could
contact the drill bit or other cutting tool. The workpiece
may unexpectedly shift, or your hand could slip.
3. To prevent the workpiece from being torn from your
hands, thrown, spun by the tool, or shattered, always
properly support your workpiece as follows:
•
Always position backup material (used beneath
workpiece) so that it contacts the left side of the
column.
•
Whenever possible, position the workpiece to
contact the left side of the column. If it is too short
or the table is tilted, clamp solidly to the table,
using the table slots.
•
When using a drill press vice (not included), always
fasten it to the table.
•
Never do any work freehand (hand-holding the
workpiece rather than supporting it on the table),
except when polishing or sanding.
•
Securely lock the head and support to the column,
the table arm to the support, and the table to the
table arm, before operating the drill press.
•
Never move the head or the table while the tool
is running.
•
Before starting an operation, jog the motor switch
to make sure the drill or other cutting tool does not
wobble or cause vibration.
•
If a workpiece overhangs the table so it will fall
or tip if not held, clamp it to the table or provide
auxiliary support.
•
Use fixtures for unusual operations to adequately
hold, guide, and position workpiece.
•
Use the spindle speed recommended for the
specific operation and workpiece material. Check
the panel on the inside pulley cover or refer to the
"Recommended Drilling Speed" section for drilling
speed information. For accessories, refer to the
instructions provided with each accessory.
4. Never climb on the drill press table, it could break or
pull the entire drill press down on you.
5. Turn the power "OFF" at the outlet when leaving the
drill press.
6. To avoid injury from thrown work or tool contact, do not
perform layout, assembly, or setup work on the table
10
