DMX-protocol
DMX channel
CH 1
RGB color control
(CH1 0 - 24)
Mode 1-8
(CH1 25 - 224)
Sound control
(CH1 225 - 255)
DMX XLR-connection
DMX IN
2
1
3
Connection between controller and the LED light effect and between another DMX light effect must be
made with 2 core screened cable, with each core having at least a 0.5mm diameter. The XLR's are
connected as shown in the table above. Note, care should be taken to ensure that none of the connections
touch the body of the plug or each other. The body of the plug is not connected in any way. The Polaris
accepts digital control signals in standard DMX512 (1990) format. Connect the controller's output to the
first fixture's input, and connect the first fixture's output to the second fixture's input. The rest may be
deduced by analogy. Eventually connect the last fixture's output to a DMX terminator.
The Polaris LED effect uses 3-pin XLR plug / socket. If your controller uses 5-pin XLR plug / socket, you
should use a conversion cable from 5-pin to 3-pin as shown bellow.
5 PIN SOCKET
Pin 1: GND (Screen)
Pin 2: Signal (data -)
Pin 3: Signal (data +)
Pin 4: N/C
Pin 5: N/C
DMX scale
0
24
25
49
50
74
75
99
100
124
125
149
150
174
175
199
200
224
225
255
CH2 0
255
CH3 0
255
CH4 0
255
CH5 0
255
CH6 0
255
CH 2-4,6
CH5 0
255
CH2-6
DMX OUT
2
1
3
3 PIN PLUG
Pin 1: GND (Screen)
Pin 2: Signal (data -)
Pin 3: Signal (data +)
Detail function
RGB color control
Mode 1
Mode 2
Mode 3
Mode 4
Mode 5
Mode 6
Mode 7
Automatic mode
Sound control mode
Red luminance weak
Green luminance weak
Blue luminance weak
Strobe speed
luminance
strong
No changing
Speed quick
No changing
DMX 512
PIN
FUNCTION
1
GND
2
DATA -
3
DATA +
5 PIN PLUG
Pin 1: GND (Screen)
Pin 2: Signal (data -)
Pin 3: Signal (data +)
Pin 4: N/C
Pin 5: N/C
5
strong
strong
strong
slow
quick
weak
slow
3 PIN SOCKET
Pin 1: GND (Screen)
Pin 2: Signal (data -)
Pin 3: Signal (data +)
