f) Slave Mode
• Use the button FUNC to select the setting SLNd.
• Push the ENTER button. The display flashes.
• Select the setting SLAv with the UP and DOWN buttons.
• Confirm the setting with the button ENTER while the display is flashing.
If no master signal is pending at the DMX-input, the display will show Stby.
g) Use with an external DMX Controller
Each DMX device in a DMX chain requires a so-called DMX starting address to be clearly identified by the controller.
This DMX starting address specifies the first DMX channel to which the effect light responds. The remaining control
channels come after this first DMX channel (DMX starting address).
The effect light requires 2 DMX channels.
Setting the DMX starting address
• Use the button FUNC to select the setting Addr.
• Push the ENTER button. The display flashes.
• Select the desired start address (001-511) with the UP and DOWN buttons.
• Confirm the setting with the button ENTER while the display is flashing.
The following table provides information about the effects of the settings on the individual DMX channels.
DMX CH CH Value
0
CH1
1-255
0-10
CH2 11-127
128-255
28
Function
Light off; device without function
Total brightness (dimmer)
Continuous light
Sound-to-light mode
Strobe from slow to fast
Note
CH2 only works in conjunction with CH1
