OUTSIDE THE CABIN:
3
Position the template level on the outside,
taking as reference the Ø4 bore made,
mark and make the remaining bores.
! Caution: The template Ø35 borehole is not
necessary.
3
If the cabin is metal, paint the boreholes
3a
with the supplied rustproof product.
Position M6 studs in the interior with a nut and
4
washer as indicated.
M6x140 Stud
Secure the exterior with a rubber washer, a flat
5
washer and a self-locking nut, securing it at
the bottom with a Ø10 socket wrench.
Ø 7
Ø 45
Ø 19
Ø6 flat wide-flanged washer
M6 Nut
15 mm
3
4
5
