TX25
4. Montage und Aufstellung
4. Assembly and siting
4. Montage et implantation
4.2 Einbau Kabelkanal, Profilschienensystem standard
4.2 Installing the cable duct – Mounting angles, standard
4.2 Montage de la goulotte de câbles – montants « standard »
19˝-Profilschienen an Tiefenstrebe
vorne
19˝ mounting angles on depth stay,
front
Montants 19˝ sur traverse latérale
avant
A
A/B
C/D
Kabelkanal VX IT / Cable duct VX IT / Goulotte de câbles VX IT
19˝-Profilschienen an Tiefenstrebe
hinten
19˝ mounting angles on depth stay,
rear
Montants 19˝ sur traverse latérale
arrière
B
R
F
1
4x
1
4x
19˝-Montagerahmen vorne
19˝ mounting frame, front
Cadre de montage 19˝ avant
C
1
Alternative
5 x 12
4x
M
= 5 Nm
A
1
Alternative
5 x 12
4x
M
= 5 Nm
A
19˝-Montagerahmen hinten
19˝ mounting frame, rear
Cadre de montage 19˝ arrière
D
R
F
13
