CONNECTION DIAGRAM
EN
BASIC SYSTEM
WITH RECOMMENDED QUICK
FOR WINDLASS OPERATION
PT 700 R - PT 1000 R
PT 700 G - PT 1000 G
WINDLASS
-
BATTERY
HYDRAULIC-
MAGNETIC
CIRCUIT BREAKER
(SEE TABLE ON
PAGE 12)
L4
L5
C
18
ACCESSORIES
®
MULTI-PURPOSE
WATERTIGHT HANDHELD
REMOTE CONTROL
MOD. HRC 1002
+
L1
L2
L3
M1
M2
L2
REVERSING CONTACTOR UNIT
MOD. T6411-12 (12V)
HANDHELD
CHAIN COUNTER
MOD. CHC 1102 M
RRC RADIO REMOTE CONTROLS
RECEIVER
MOD. R02
FOOT SWITCHES MOD. 900U AND 900D
BLACK
BROWN
BLUE
FUSE
4A (12V)
2A (24V)
A2
WINDLASS CONTROL
BOARDS MOD.800
MOD. WCS810
STRAP-ROLLER
WITH SPRING
CATCH (PTG)
TRANSMITTERS
POCKET
HANDHELD
MOD. P02
MOD. H02
A1
L = L1 + L2 + L3 + L4 + L5
PONTOON 350 - 700 - 1000 - REV002A
