Contents
Figure 1: Controls and Connections
Figure 2: Stereo Connections
Figure 4: Balanced Input Connection
Contents ............................................... 5
About Rotel .......................................... 5
Getting Started ..................................... 5
AC Power and Control ........................... 6
and Output
Input Signal Connections ........................ 7
Speaker Connection ............................... 7
Troubleshooting ..................................... 8
Specifications ........................................ 8
5
About Rotel
3
A family whose passionate interest in music
led them to manufacture high fidelity compo-
4
nents of uncompromising quality founded Rotel
4
over 40 years ago. Through the years that
passion has remained undiminished and the
family goal of providing exceptional value for
audiophiles and music lovers, regardless of
their budget, is shared by all Rotel employ-
ees.
The engineers work as a close team, listen-
5
ing to, and fine tuning each new product until
it reaches their exacting musical standards.
6
They are free to choose components from
6
around the world in order to make that product
the best they can. You are likely to find ca-
pacitors from the United Kingdom and Ger-
6
many, semi conductors from Japan or the
United States, while toroidal power transform-
6
ers are manufactured in Rotel's own factory.
6
Rotel's reputation for excellence has been
6
earned through hundreds of good reviews and
7
awards from the most respected reviewers in
the industry, who listen to music every day.
Their comments keep the company true to its
7
goal - the pursuit of equipment that is musi-
cal, reliable and affordable.
7
7
All of us at Rotel thank you for buying this
product and hope it will bring you many hours
of enjoyment.
7
Getting Started
7
7
Thank you for purchasing the Rotel RB-1080
8
Stereo Power Amplifier. When used in a high-
quality music or home theater system, your
Rotel amplifier will provide years of musical
8
enjoyment.
8
8
8
The RB-1080 is a high-power, two-channel
power amplifier, providing the highest level
of audio performance. Discrete output devices,
a massive power supply, premium components,
and Rotel's Balanced Design ensure superb
sound quality. High current capability allows
the RB-1080 to drive the most demanding loud-
speakers.
Be aware that the RB-1080 is capable of high
power levels, in excess of 200 watts per chan-
nel. Make sure that your speakers can handle
the power of the RB-1080. If in doubt about
your speakers, ask your local Rotel audio
dealer for advice.
The RB-1080 is straightforward in its instal-
lation and operation. If you have experience
with other stereo power amplifiers, you
shouldn't find anything perplexing. Plug in a
pair of high-quality RCA cables from your
preamp into the amplifier inputs, wire up your
speakers, and enjoy. Alternatively, the RB-1080
provides an optional pair of balanced inputs
for use with preamps or processors that of-
fer these low-noise XLR-connections. If you
choose this option, you will need to reset a
back panel switch selecting the balanced in-
puts. Again, nothing very confusing.
A Few Precautions
Please read this manual carefully. In addition
to basic installation and operating instructions,
it provides valuable information on various
RB-1080 system configurations as well as gen-
eral information that will help you get opti-
mum performance from your system. Please
contact your authorized Rotel audio dealer
for answers to any questions you might have.
In addition, all of us at Rotel welcome your
questions and comments.
Save the RB-1080 shipping carton and all en-
closed packing material for future use. Ship-
ping or moving the RB-1080 in anything other
than the original packing material may re-
sult in severe damage to your amplifier.
Fill out and send in the owner's registration
card packed with the RB-1080. Also be sure
to keep the original sales receipt. It is your
best record of the date of purchase, which you
will need in the event warranty service is ever
required.
