Face supérieure
Touche [INSERT/COPY]
Touche [DELETE/ERASE]
Touche [BASS MUTE]
Afficheur
Touche [BANK]
Touche [BASS]
Touche [DRUM]
Face arrière
Commande [VOLUME]
Prise [PHONES]
ZOOM RT-223
Noms des parties
Touches VALUE [+]/[-]
Touches curseur
Touche [REPEAT/STEP]
Touche [KIT/PROG]
Prise [R OUT]
Prise [LINE IN]
Prise [L/MONO OUT]
Pads
Touche [FUNCTION]
Connecteur
Connecteur [MIDI IN]
[DC IN]
Prise [FOOT SW]
Interrupteur [POWER]
Touche [SONG]
Touche [TEMPO]
Touche [PATTERN]
Touche [COMP EQ]
Touche [REVERB]
Touche [EXIT]
Touche [METRONOME]
Touche [EDIT]
Touche REC [O]
Touche PLAY [R]
Touche STOP [P]
