6.1.1 Minimum distance from combustible material

B
B
B
B
E
E
A = clearance to mantel
B= clearance to sidewall
C = clearance to face trim (side)
D = clearance to face trim (top)
E = floor protection
F = floor protection
G = clearence to front
I = mantel depth
J = ceiling from bottom of unit
K = combustible floor from
bottom of the glass
User and maintenance manual for stoves with RDS technology
C
C
May be made of combustible material
May be made of combustible material
Wall may be made of combustible material (zero clearance)
Wall may be made of combustible material (zero clearance)
E
E

Unit of measurement

I
I
Wall may be made of combustible material (zero clearance)
Wall may be made of combustible material (zero clearance)
Inch/mm
Inch/mm
Inch/mm
Inch/mm
Inch/mm
Inch/mm
Inch/mm
Inch/mm
Inch/mm
Inch/mm
01/02/2016
Pag.11
G
G
Combustible floor
Roma
18,5/470
15/381
0/0
0/0
6/152.4
6/152.4
48/1219
6/152.4
72/ 1828.8
9.5/241.3
