Inducti ve signal transmission system
5. System components fi tt ed to the gate
1
10 1 2
3 11 3
3 6 4 6 1 2
2 2 2
Example of use
The actual arrangement of the individual components
depends on the design of the gate in questi on and the
conditi ons at the installati on site.

6. Device overview

6.1 Signal Indicators

LED Power (green)
Operati ng state (on)
Error message (pulse output)
LED Transmit Opening (red)
travelling edge(s) for opening movement
actuated / interrupted (on)
LED Stati onary Opening (red)
stati onary edge(s) for opening movement
actuated (on) - interrupted (fl ashes)
LED Transmit Closing (red)
travelling edge(s) for closing movement
actuated / interrupted (on)
LED Stati onary Closing (red)
stati onary edge(s) for closing movement
actuated (on) - interrupted (fl ashes)
V1.0: If no error is present, then LED Power shows the functi on control (briefl y off ).
V4.0 and later: If no error is present, then LED Power shows the operati ng state (on).
During the output of an error message, the number of output pulses indicates the error:
Pulse Error message
1 Voltage supply outside of the valid value range
2 Inducti ve signal transmission system error
3 Output control Open faulty
4 Output control Close faulty
5 Data transmission with microcontroller faulty
6 Testi ng sensor input faulty (stati onary safety contact edges) (Open/Close)
16
2
1 ELMON inducti ve 71-752 control device
2 Stati onary coil core
3 Travelling coil core
4 Steel cable acti ng as transmission medium
4 3
ELMON inducti ve
71-752
