ICEMAKER INSTALLATION INSTRUCTIONS H
Are these the right instructions for your model? Follow the Installation Instructions indicated by
the label on the back of the refrigerator—
NOTE: If you have refrigerator model TNS22 or TNX22, please refer to the installation
instructions for , instead of using the
P
BEFORE YOU BEGIN
Read each step thoroughly before proceeding.
CAUTION –
•
Refrigerator. To eliminate the danger
of electric shock during installation,
you must unplug the refrigerator
from its electrical outlet.
TOOLS YOU WILL NEED
Flat blade and Phillips
screwdrivers
PREPARE FOR INSTALLATION
1
•
Remove and discard the white
plug from the upper left
corner of the freezer wall.
INSTALL WATER TUBE INLET
2
• Locate the hole in the upper right corner on
the back of the refrigerator and, using a knife,
clear the foil from the hole.
• Remove the gray insulation plug from the hole.
NOTE: It may be necessary to remove the screw
from the top right condenser mounting clip for
better access to the hole (see page 25, Step 4).
• Cut the fill tube (16) to the
H
the template on page 66), with a sharp knife
or a single-edge razor blade.
• Slide the fill tube (16) onto
the water tube inlet (15).
• On the tube side of the water
tube inlet (15) there is an
adhesive backing. Remove
the backing. Slide the tube
into the hole on the back
of the refrigerator as
shown. Firmly press on
the inlet to secure it.
Installation Instructions
C
instructions.
H
Unplug the
Sharp knife
Pliers
Remove
plug
H
length (refer to
16
15
F G H J K L M
3 REMOVE PLUG COVER
• Remove the electric plug cover
from the left side wall and discard it.
• Remove the screw and pull the
cover off.
LOOSEN MOUNTING SCREWS
4
Loosen the two mounting screws (A) but do not
screw them all the way out. The screws should
extend approximately 1/2" (13 mm) out from
the freezer wall.
5 SET POWER SWITCH TO O (off)
Set the icemaker power switch to O (off). Leave
the power switch in the O (off) position until the
refrigerator is connected to the water supply to
prevent premature operation.
Power
Switch
22
or S
N P Q R
A
Hole for
wire tie
