Ibiza Light IBIZA200FIREFLY Manuel De L'utilisateur

RED-GREEN-BLUE DMX
LASER 200mW
IBIZA200FIREFLY
User's manual
Manuel de l'Utilisateur
Bedienungsanleitung
Manual de Instruções
IMPORTANT NOTE: Electric products must not be put into household waste. Please
bring them to a recycling centre. Ask your local authorities or your dealer about
the way to proceed.
NOTE IMPORTANTE : Les produits électriques ne doivent pas être mis au rebut avec
les ordures ménagères. Veuillez les faire recycler là où il existe des centres pour
cela. Consultez les autorités locales ou votre revendeur sur la façon de les recycler.
WICHTIGER HINWEIS: Elektrogeräte gehören nicht in den Hausmüll. Sie müssen in
speziellen Betrieben recycelt werden. Bringen Sie sie zu einer speziellen Entsorgungsstelle für
Elektrokleingeräte (Wertstoffhof)!
Produtos eléctricos não deverão ser postos em contentores de lixo caseiros. Por favor, deposite-os
em contentores para reciclagem. Questione as autoridades locais ou onde adquiriu o produto
sobre como deverá proceder.
Imported from China by:
LOTRONIC SA
Avenue Zénobe Gramme 11
1480 SAINTES
© Copyright LOTRONIC 2013
www.lotronic.com
Belgium
GB – USER MANUAL
Thanks for your purchasing, please read this manual carefully
before operating the system. It gives you general information for
your safe and better operation.
INSPECTION
Check for the contents in the package refer to the following
1. Laser lighting: 1
2. Power cable: 1
3. User's manual: 1
Function Setting for LASER
0=OFF 1=ON X=OFF or ON
DIPSWITCH CHART
#1 #2 #3 #4 #5 #6 #7 #8 #9 #10
0 X X X X X X
X X X X X X
1
SET DMX ADDRESS FOR DMX MODE
Installation
1. Firstly, be sure that the using voltage is match with the voltage marked
on the base of the laser lighting;
2. Installation should be made by professional technician. Fix the laser
lighting and adjust the angle of the laser lighting to you need;
3. Please check whether the fan or the exhaust are blocked;
4. There is a hole for connection. When hang the laser lighting, be sure
the cable can support 10 times the weight of the unit;
5. The laser lighting should be fixed;
6. It is essential to be earthed well for the sake of safety.
DMX512
This laser light is controlled by the standard DMX. Please connect
controlling panel with the lighting as following
list:
FUNCTION
X X
1 SOUND ACTIVE
X X
1 AUTO MODE
0 DMX/SLAVE
IBIZA200FIREFLY
1
