The Control Board system is an intricate and valuable piece of technology. For protection from power surges and electrical shorts,
consult the wire diagram below to ensure your power source is sufficient for the operation of the unit.
PB – ELECTRIC REQUIREMENTS
INPUT: AC 110-120V, 60HZ, 3-PRONG GROUNDED PLUG
OUTPUT: DC 12V / 90W
NOTE: Electrical components, passed by product safety testing and certification services, comply
with a testing tolerance of ± 5-10 percent.
DISCONNECT POWER
SUPPLY BEFORE SERVICE
OR MAINTENANCE.
FUEL INPUT
RATING:
1.12 KG/H
(2.48 LB/H)
SIDE SHELF LIGHT SWITCH
AUGER MOTOR & FEED SYSTEM
12V DC, 4.5 RPM
INDEX
K : BLACK
BLOWER FAN
B: BLUE
12V DC
W : WHITE
R : RED
Y : YELLOW
P : PURPLE
G : GREEN
O: ORANGE
N: BROWN
ELECTRICAL WIRE DIAGRAM
REMOVE THE EIGHT
SCREWS TO ACCESS THE
SMOKER COMPONENTS.
CONTROLLER
R
G
K
Y
W
K
W
G
Y
R
B
Y
R
K
LED LIGHT
B
R
Y
O
R
P
Y
K
N
W
K
B
Y
O
R
P
B
N
W
K
B
Y
R
K
O
W
LIGHT
AC/DC POWER
R
K
AC/DC ADAPTER
INPUT: 100~240V AC
W
OUTPUT: 12V DC
K
GROUND
GROUNDED
PLUG
IGNITER
12V DC, 45W
W
W
GRILL
PROBE
27
