When the Programmable Meat Probes are plugged-in at the connection ports, these icons will display. The Actual
temperature is shown in bold and the Set temperature, if one is set, will be shown below. Move to or touch P1 or
P2 on the Main Screen. Rotate the Controller Knob to adjust the desired temperature and push the knob or touch
P1
to confirm the selection. To access the Probes sub-screen, touch or move the joystick up if hovering over P2, and
165
down if hovering over P1. Under the Probes sub-screen, select the probe, then the temperature to program, or
select the protein icon to set the default temperature for what is being cooked. When not in use, disconnect the
204
Meat Probe.
The outer ring indicates how far along the current cooking temperature is from the programmed temperature,
0-100%. See Controller Functions for more detail on using the Programmable Meat Probes.
The Settings icon will highlight blue when selected. The following menu items are available under Settings:
• P Setting: Adjusting the P Setting value allows the user to directly control the cycle rate of pellets that feed
the burn pot. The main purpose of this cooking preset is to cook at low temperatures when the unit is highly
affected by the ambient outdoor weather. See Smoke Mode.
• Display: Adjust the brightness of the display or change the temperature units to user preference. The
brightness slider can be increased/decreased. The temperature units can change from Fahrenheit (ºF) to
Celsius (ºC). Default is set to Fahrenheit (ºF).
• Screen Saver: The default is 15 Min. Select 1 Min, 3 Min, or 5 Min to choose when the display will go into
sleep mode after it has been idle, and click Lock to confirm. Press the Control Knob to wake the display.
• Start-Up: OFF is the default and will automatically heat the unit to 107°C/225°F. Touch or Move the Controller
Knob to temperature (it will be blinking blue) and rotate the wheel to modify, press the Controller Knob or
touch anywher on the screen to confirm the temperature. Select ON to keep this selected temperature as
the new default start-up temperature. The temperature range is 54-215°C/130-420°F.
• Language: This options allows the user to change the language shown in the display. The display language
options are English, French, and Spanish; English is the default language.
• About: On this screen, you should see the controller specifications and other system information. In order
to best serve your support needs, you will need to relay this information with Customer Care. The MAC
address is a unique identifier assigned at manufacturing, useful for troubleshooting hardware concerns.
The Menu options: Hold Prime, 3 Seconds Prime, or 5 Seconds Prime. Selecting the Hold option will continuously
feed pellets from the auger, 30 seconds maximum. Press it again to stop the auger feed. The timed selections will
prime automatically for that period.
Press this button to switch on and off the light inside the smoker.
The FAN icon is visible when the fan is in operating correctly. If an error occurs with the fan, the FAN error screen
will appear. See the section on troubleshooting for assistance.
The IGNITER icon is visible when the igniter is in operating correctly. If an error occurs with the igniter, the IGNITER
error screen will appear. See the section on troubleshooting for assistance.
The AUGER icon is visible when the auger is in operating correctly. If an error occurs with the auger, the AUGER
error screen will appear. See the section on troubleshooting for assistance.
The PELLET error screen will appear if there is an error, the fire in the Burn Pot has gone out or the hopper may be
empty. See the section on troubleshooting for assistance.
17
