8.1 INTRODUCTION

Initialization is the function by which the instrument is returned to its original settings pre-set by the manufacturer,
eliminating all the modifications made by the user. The Canticus organ is able to perform both the general
initialization procedure (all sections of the instrument are reset to their original values) and sectorial initialization
procedures. In view of the characteristics of the initialization process, you are advised to save data considered important on
disk before starting the operations described below.

8.2 GENERAL INITIALIZATION OF THE INSTRUMENT

To obtain a general initialization of the instrument starting from the main video page (volume level control), press the
×
PAGE key twice. After passing through the presentation video page, the display will show:
L       L
31&   : 9 ; ," 230, 2&# .-5#0 -,
The software release installed on the instrument appears in the top right-hand corner of the display: state this code whenever
you contact the after-sales service.
Then switch the organ off and back on, keeping the push-buttons of the general memories HR 1 and 2 pressed.

8.3 INITIALIZING AN INDIVIDUAL VOICE

Canticus also allows the user to restore the parameters of a single voice, from any manual, to its original values. To do this
starting from the main video page, press the TAB key. The display will now be divided into 4 columns corresponding to the
3 sections of the organ (pedal section, man. I and man. II): the name of the section appears at the top of each column, and
the name of the first voice in the section at the bottom. Use the
containing the voice to be initialized. Turn the Encoder to scroll through all the voices in the chosen section until the name
of the voice for modification appears on the display.
×
Press the PAGE key (the voice parameters appear on the display) and then the PAGE
simultaneously. Then press EXIT to leave the function.

8.4 VOICE LOCAL OFF

If the Canticus organ is piloting an external sound generator by MIDI, it may be necessary to switch one or more voices to
"Local off" mode. When a voice is in "local off" mode, when its stop is operated, only the MIDI code will be emitted,
without activating sound generation (the voice is mute).
To set one or more voices in "local off" mode, press the SET (S) push-button under the first manual and keep it pressed
while pressing the CANCEL (C) push-button also under the first manual.
When this is done, all the lamps of the enabled voices will illuminate; the selectors can also be used to disable local off, or
enable normal operation of the individual voices. Remember that in this operating mode, when the light of the selector is
off, voice generation is disabled.
Press the SET + CANCEL keys again to return to normal operation.

8.5 INITIALIZING THE TUTTI REGISTER (CANTICUS II only)

To return the TUTTI register to the original settings, starting from the main video page press the PAGE
necessary to obtain the following video page on the display:
L  4-'!#     L
31&   : ," 230, 2&# .-5#0 -,
Viscount CANTICUS I - II
8. INITIALIZATION PROCEDURES
 BC9=
Õ Ö
and cursor keys to locate the cursor under the section
57
× Ø
and PAGE keys
×
key as often as
