See manual connection set
05
Blind plug 1/2" and air vent 1/8" need
to be tightened to 5Nm with a torque
wrench -airvent only the outer screw.
Bleeding: use a key to hold the air vent in
position while opening the inner screw for
bleeding. Bleed and check the unit for
leaks before installing the casing.
07
09
JAGA N.V. | LINEA PLUS HYBRID - ACO/B | MANUEL | 2024.09.12 | V.1.02
04
06
08
«CLICK»
10
± 2cm
Clean
and degrease
before
sticking!
± 1cm
«CLICK»
SW.10
