1 Humidity sensor (FTS2)
2 Status output
3 Remote start
4 Additional output (max. 3.5 kW)
5 Vaporizer (max. 3.5 kW)
6 Heating system (max. 10.5 kW)
7 Power supply for the
sauna control unit
a
9
8
8 Power booster
9 Fan
a Light
b
Earthing bar
c Heater sensor with over-
heat cut-out (F1)
d Bench sensor (F2)
e Foil sensor
7
6
5
c
139 °C
b
3
2
4
d
e
1
