DIANDRA 60 S-LINE - DIANDRA 90 S-LINE
ITEM DESCRIZIONE
1 PIPE PELLET FEED
2 TUBE ELETRIC HEATER
3 AUGER SUPPORT
4 BURNER SUPPORT
5 SMOKE LOWER LEFT SIDE
6 SMOKE LOWER RIGHT SIDE
7 SMOKE RIGHT SIDE
8 SMOKE LEFT SIDE
9 SMOKE LOWER CENTRAL
10 LEFT SIDE INTERNAL PANEL
11 RIGHT SIDE INTERNAL PANEL
12 FLAME SHIELD
13 DUCT SUPPORT PANEL
14 REAR LOWER PANEL
15 UPPER REAR PANEL
16 AIR GRILLE
17 LOWER PANEL DOOR
18 RIGHT SIDE PANEL
19 LEFT SIDE PANEL
20 TOP
21 PELLET DOOR
22 PELLET TANK
23 SEAL PIPE PELLET FALL
24 SPHERIC PLASTIC HANDLE
25 GEAR SUPPORT
26 GEAR MOTOR MEM390 230/50/2RPM
27 DIFFERENTIAL AIR PRESSURE SWITCH C6065A1002:2 0.6-6MB
28 THERMOSTAT 100°C LS16025516 2.5AT85
29 ELECTRIC HEATER 270W 230V X 6-8
30 POWER SUPPLY
31 ADJUSTABLE FEET
32 HOLDING AUGER
33 BUSHING FOR AUGER
34 SMOKE EXTRACTOR
35 CENTRIFUGAL FAN
36 PCB J042
37 BURNER
38 AUGER
39 GLASS
40 EXTERNAL FRAME DOOR
41 INTERNAL FRAME DOOR
42 HANDLE
Ø DISPLAY
Ø DOOR SEAL DIAM 14MM
Ø GLASS SEAL 15X3MM
Ø FLAT CABLE FOR DISPLAYER
Ø CABLING
Ø REMOTE CONTROL
Ø ROOM SENSOR STUFA
Ø USER MANUAL
Ø INSTALLATION MANUAL
Ø particolare non rappresentato nell'esploso.
DIANDRA90
UM Q.TA' COD.
NR 1 161402020A
NR 1 161402026A
NR 1 161402030A
NR 1 161402032A
NR 1 161402034
NR 1 161402035
NR 1 161402037
NR 1 161402037-L
NR 1 161402039
NR 1 161402041
NR 1 161402041-L
NR 1 161402052
NR 1 161402057
NR 1 161402059
NR 1 161402060
NR 1 161402062
NR 1 161402063
NR 1 161402064-90
NR 1 161402066-90
NR 1 161402068-90
NR 1 161402069-90
NR 1 161402070-90
NR 1 161402073
NR 1 161402075
NR 1 161402081
NR 1 410006
NR 1 410007H
NR 1 410009
NR 1 410010R
NR 1 410011
NR 4 410023A
NR 1 410056
NR 2 4100650T
NR 1 410694
NR 1 411188N
NR 1 411300
NR 1 411688
NR 1 414935
NR 1 410016
NR 1 43102901
NR 1 43102902
NR 1 4312908A
NR 1 411300
ML 1 410020
ML 1 410029
NR 1 410238
NR 1 420005
NR 1 410673
NR 1 410240
NR 1 001170
NR 1 001171
DIANDRA60
COD.
161402020A
161402026A
161402030A
161402032A
161402034
161402035
161402037
161402037-L
161402039
161402041
161402041-L
161402052
161402057
161402059
161402060
161402062
161402063
161402064A
161402066A
161402068A
161402069
161402070A
161402073
161402075
161402081
410006
410007H
410009
410010R
410011
410023A
410056
4100650T
410694
411188N
411300
411688
414935
410016
43102901
43102902
4312908A
411300
410020
410029
410238
420005
410673
410240
001170
001171
