Read the safety warnings carefully before using
the appliance.
1. DESCRIPTION
1.1 Description of appliance (A)
A1. Control panel
A2. Condensate collection tank
A3. Lifting handle
A4. Air intake
grill
A5. Dust Air filter or silver-ion air filter (on
certain
models only)
A6. Air outlet grill
A7. Castors (on certain models only)
A8. Condensate drain hose (approx. 1 m)
A9. Anti-allergen filter (on certain models only)
A10.Activated carbon filter (only in certain
models)
1.2 Description of control panel (B)
B1. ON/STAND-BY button
B2. Dehumidifying button
B3. Dry button
B4. Timer button
1.3 Description of display (C)
C1. Dehumidifying mode active
C2. Dry mode active
C3. Low temperature alarm
C4. Digits for % Relative Humidity/timer hours
C5. Full tank alarm
C6. Timer function active
2. SETTING IT UP FOR USE
Position the appliance in the room to be
dehumidified.
It is essential to leave a free space of at least 50
cm in front of and above the dehumidifier, so as
not to obstruct the air intake and outlet. For
efficient ventilation it is advisable to leave a
space of at least 5-10 cm all around the
appliance.
3. APPLYING THE CASTORS
To apply the castors to the appliance, proceed as
follows:
1. Make sure the appliance is unplugged and
the tank is empty.
2) Apply the castors as shown in fig 1 and slide
them as shown by the arrow (fig. 2) till
hooked in position.
4. DRAINING THE CONDENSATE WATE
The condensate can be drained in 2 ways:
4.1 Draining into the tank
The condensate is drained directly into the tank
(A2). When the tank is full, the appliance stops
and the control panel (B) displays a red tank
alarm (C5).
To restore operation of the appliance, proceed as
follows:
1. Remove the tank (fig. 3) and empty it into a
sink or bathtub.
2. Replace the tank in its housing, making sure
it's properly positioned.
Continuous external draining
4.2
If the appliance is used for long periods of time
without the possibility to regularly empty the
tank, the continuous drain function should be
used. Proceed as follows:
1. Remove the continuous drain cap from the
spout, turning it in an anti-clockwise
direction, then remove the rubber stopper
from the opening (fig. 4). (Watch out for any
leaking water!)
2. Attach the condensate drain hose (A8) to
the spout (fig. 5).
3. Make sure the hose is positioned below the
spout (fig. 6), or the water will flow back into
the tank of the appliance.
Also make sure there are no kinks in the hose.
5. MODE SELECTION
Connect the appliance to the mains supply.
Upon first use, a dot will appear on the display
and at the same time, an acoustic signal will
sound to indicate that the appliance is in stand-
by mode.
