TOOLS NEEDED
•
5/16" nut driver
•
1/4" nut driver
PARTS INCLUDED IN KIT
•
Deflector (2)
•
#8 x
/
" sheet metal screws (4)
3
8
•
#8 x
1
/
" self tapping screws (2)
2
STEP 1A
On models with straight outdoor coils, mount grills as
shown in Figure 1 ensuring the foam gasket is facing
away from the chassis. Install two (2) #8 x
per grill to secure.
Figure 1
Figure 3
RAK40
• Do not use screws longer than 3/8" when mounting
deflector to metal end brackets. Doing so may damage
heat exchanger.
• Only use this Kit when not using a GE Appliances grill.
If existing grill has air deflector attached, remove the
deflector before mounting grill.
STEP 1B
• On models with "L" shaped outdoor coils, mount left
hand grill as shown in Figure 1 ensuring the foam
gasket is facing away from the chassis. Install two (2)
3
/
" screws
#8 x
8
when looking at the back on unit).
• Mount right hand grill as shown in Figure 2 ensuring
#8 x
3
/
" screw (4)
8
the foam gasket is facing away from the chassis.
Install two (2) #8 x
shroud (right side of unit when looking at the back on
unit) to secure.
CAUTION
3
/
" screws on sheet metal end of coil (left side
8
1
/
" self taping screws in plastic
2
Plastic shroud
Figure 2
#8 x
/
" screw (2)
1
2
31-5000801 Rev. 0 02-24
