Adjustments
5 Adjustments
4
The lorry loading crane must be matched to the required load capacity of the pallet fork!
To pick up parcels correctly, the pallet fork must be prepared as follows:
•
The fork spacing must be adjusted to the package
•
For narrow, high parcels, the forks must not be more than 5 cm away from the end of the
parcel, otherwise the parcel may tip over! Danger to life!
The fork spacing is set as follows:
•
Loosen the screws (2) on the forks (1)
•
Move the forks (1) on the upright (3) until the corresponding position is reached
•
Tighten the screw (2) again
56000010 / 56000011 / 56000025 / 56000024
5
6
2
3
14 / 21
