IMPORTANT INSTRUCTIONS BEFORE INSTALLATION

Failure to follow these instructions may cause serious bodily injury and/or property damage.
Warranty void if product modified, drilled, painted,
or altered in any way; if used to pump hot water, or
to pump liquids other than water (such as but not
limited to chemicals, fertilizers, flammable liquids, herbicides,
mud, tar, cement, wood chips); or otherwise abused.
READ THESE RULES AND INSTRUCTIONS CAREFULLY.
WARNING: Risk of electric shock – This pump is supplied
with a grounding conductor and grounding type attachment
plug. To reduce the risk of electric shock, connect only to a
properly grounded grounding-type receptacle. This pump has
not been investigated for use in swimming pool areas. Read
instructions before installing pump.
1. Before installing or servicing your pump, BE CERTAIN
pump power source is disconnected.
2. Installation and electrical wiring must adhere to state
and local codes and must be complete before priming pump.
Check appropriate community agencies, or contact local
electrical and pump professionals.
3. CALL AN ELECTRICIAN WHEN IN DOUBT. Pump should be
connected to a separate 15 amp circuit breaker or 15 amp
fuse block. Plugging into existing outlets may cause low
voltage at motor, causing blown fuses, tripping of motor
overload, or burned-out motor.
4. A permanent ground connection from pump to the
grounding bar at the service panel is mandatory. WATER ACE
PUMP CO. sump pumps come with a grounding conductor and
a grounding-type attachment plug. Do not connect pump to
a power supply until permanently grounded. For maximum
safety, connect pump to a circuit equipped with a fault
interrupter device.
5. Voltage of power supply must match the voltage of the
pump. All WATER ACE PUMP CO. sewage pumps are factory
preset to 115V, 60 Hz.
6. Before installing pump, clear sump basin of any water,
debris, or sediment. WARNING: Sump basin must be
vented in accordance with local plumbing codes. WATER
ACE PUMP CO. sewage pumps are not designed for and
CANNOT be installed in locations classified as hazardous
in the National Electric Code, ANSI/NFPA 70. These pumps
have not been investigated for fountain or swimming
pool areas.
7. The sump basin should be 18" in diameter and made of
plastic, fiberglass, or concrete. It must be equipped with
a gasketed, properly vented cover. Consult local plumbing
codes for correct vent size.
WA-23833A602
8. The following may cause severe damage to pump and will
void warranty:
• Using an extension cord.
• Cutting off the ground pin or using an adapter fitting.
• Working on pump or switch while plugged in.
• Removing motor housing, unscrewing impeller,
or otherwise removing impeller seal.
• Running the pump continuously.
• Pumping chemicals or corrosive liquids.
• Pumping gasoline or other flammable liquids.
9. SAVE THESE INSTRUCTIONS.
PIPING
PVC pipe is shown in the illustrations, but galvanized steel
or copper pipe may be used if desired. All piping must be
clean and free of all foreign matter to prevent clogging.
INSTALLATION INSTRUCTIONS
Refer to the installation illustration on the following
page for the following instructions. Be certain sump
basin is clean and all power to pump is shut off. If pump
fails to operate properly after installation, refer to the
troubleshooting checklist on page 3 or contact WATER ACE
PUMP CO. All parts with part numbers are quality WATER ACE
PUMP CO. parts.
General Materials Needed
• One can PVC cement (read instructions carefully).
• One can thread compound (read instructions carefully).
• Three 2" male PVC adapters.
• Enough 2" rigid PVC pipe and couplings to reach from
bottom of sump basin to discharge.
• One 2" PVC elbow.
• One 2" free-flow check valve RCVP-20S.
• One shut-off gate valve.
• Basin with gasketed cover and vent.
Tools needed for all pump installations
Pipe wrench, sloted screwdriver, 24-tooth hacksaw, knife or
round file.
BASIN AND COVER REPAIR PARTS
25536C101 Cover, Solid for 2" or 3" Vent
25533D100 Basin 18 x 30 for Solid Covers
