GB
F D E I P
Figure 11
44. Trimmer line cut-off blade
Figure 14
45. Start position
46. Run position
Figure 16
47. Tri-arc Blade
Figure 17
48. Idle speed screw
Figure 18
19. Latch
Figure 19
19. Latch
49. Filter screen
50. Air filter cover
ASSEMBLY
UNPACKING
This product requires assembly.
Carefully remove the tool and any accessories from
■
the box. Make sure that all items listed in the packing
list are included.
Inspect the tool carefully to make sure no breakage
■
or damage occurred during shipping.
Do not discard the packing material until you have
■
carefully inspected and satisfactorily operated the
tool.
If any parts are damaged or missing do not operate
■
this product until the parts are replaced. Failure to
heed this warning could result in serious personal
injury.
WARNING:
Do not attempt to modify this product or create
accessories not recommended for use with this
product. Any such alteration or modification is
misuse and could result in a hazardous condition
leading to possible serious personal injury.
WARNING:
To prevent accidental starting that could cause
serious personal injury, always disconnect the
engine spark plug wire from the spark plug and
remove battery pack when assembling parts.
INSTALLING THE POWER HEAD SHAFT TO THE
ATTACHMENT
See Figure 2.
NL S DK N FIN GR HU
English
The attachment connects to the power head shaft by
means of a coupler device.
■
■
NOTE: If the button does not release completely in the
positioning hole, the shafts are not locked into place.
Slightly rotate from side to side until the button is locked
into place.
■
REMOVING THE ATTACHMENT FROM THE POWER
HEAD
For removing or changing the attachment:
■
■
ATTACHING THE HANGER CAP
See Figure 3.
There are two ways to hang your attachment for storage.
■
■
ATTACHING THE FRONT HANDLE
See Figure 4.
RBC30SET
■
■
■
NOTE: The hex bolt head fits inside the hex recess
21
CZ RU RO PL SLO HR TR EST LT
WARNING:
Never install, remove, or adjust any attachment
while power head is running. Failure to stop the
engine can cause serious personal injury.
Loosen the knob on the coupler of the power head
shaft and remove the end cap from the attachment.
Push in the button located on the attachment shaft.
Align the button with the guide recess on the power
head coupler and slide the two shafts together.
Rotate the attachment shaft until the button locks into
the positioning hole.
Tighten the knob securely.
WARNING:
Be certain the knob is fully tightened before
operating equipment; check it periodically for
tightness during use to avoid serious personal
injury.
Loosen the knob.
Push in the button and twist the shafts to remove and
separate ends.
To use the hanger cap, push in the button and place
the hanger cap over end of the lower end attachment
shaft. Slightly rotate the cap from side to side until the
button locks into place.
The secondary hole in the attachment shaft can be
used for hanging purposes as well.
Remove the bracket (item 32), washer, and bolt from
the front handle.
Install the front handle onto the top side of the drive
shaft boom with the barrier bar on the same side as
the recoil starter (compare to product images in figure
sheet or on giftbox)
Place the bolts through the front handle.
