Customer Service for assistance.
WARNING
If any parts are damaged or missing do not operate this
product until the parts are replaced. Use of this product
with damaged or missing parts could result in serious
personal injury.
WARNING
Do not attempt to modify the product or create
accessories not recommended for use with the product.
Any such alteration or modification is misuse and could
result in a hazardous condition leading to possible
serious personal injury.
WARNING
To prevent accidental starting that could cause serious
personal injury, always disconnect the engine spark
plug wire from the spark plug when assembling parts.
WARNING
Be certain the knob is fully tightened before operating
the equipment. Check the knob for tightness periodically
to avoid serious injury.
INSTALLING THE PRO CUT STRING HEAD/SHAFT/
GRASS DEFLECTOR ASSEMBLY TO THE TRIMMER
POWER HEAD/WHEEL ASSEMBLY
WARNING
Never install, remove, or adjust any attachment while
the engine is running or cutting head is moving. Failure
to stop the engine may cause serious personal injury.
connects to the trimmer power head/wheel assembly by
means of a coupler device.
Loosen the knob on the coupler of the power head
shaft and remove the end cap from the string head/
shaft/grass deflector assembly.
Push in the button located on the attachment shaft.
Align the button with the guide recess on the power
head coupler and slide the two shafts together. Rotate
the attachment shaft until the button locks into the
positioning hole.
PT NL SV DA NO FI
English (Original instructions)
HU CS RU RO PL SL
NOTE: If the button does not release completely in
the positioning hole, the shafts are not locked into
place. Slightly rotate from side to side until the button
is locked into place. If needed, turn the trimmer head,
which will aid in the insertion of the shaft.
To ensure the operator is protected from thrown or flying
objects, the rear bottom edge of the grass deflector
must be parallel to the ground. The two arrows on the
shaft should be aligned to the approximate position as
shown in figure 2.
Tighten the knob securely.
INSTALLING LOWER HANDLEBAR
Place the lower handlebar into the openings on the
trimmer power head/wheel assembly.
NOTE: Do not allow throttle cable to become pinched
when installing the handlebar.
Insert the bolts through the holes in the handlebar and
frame.
Install the lower handlebar knobs and tighten securely.
INSTALLING UPPER HANDLEBAR
Position upper handlebar onto lower handlebar. Make
sure the throttle cable and throttle trigger are on the
right side.
Insert bolt through plastic clip, then through holes.
NOTE: Do not allow throttle cable to become pinched
when installing the handlebar.
Align the holes in the clip, the upper handlebar and
lower handlebar.
Install bolt.
Thread handlebar knob onto bolt and tighten securely.
Repeat with other side.
INSTALLING NEW LINE INTO PRO-CUT STRING HEAD
replacement line supplied by or available from the
manufacturer for best performance and durability.
Stop the engine and disconnect the spark plug wire.
Gather two of the pre-cut lengths of trimmer line
provided or cut two pieces of trimmer line in 25.4 cm
lengths.
Insert the lines into the load slots located on the sides
15
