Remove the tabs with a screw driver
Side A
ee
-
or a similar object
Tab for side B
High position
à
Detection hole
Normal position
>)
Adhesive tape
RES
Concerning Cassette Tapes
Selection of cassette tapes
Cassette tapes exceeding 100 minutes:
These tapes are handy for their long playback and recording time but
be careful about repeatedly stopping and starting, rewinding and fast
forwarding these tapes in short intervals as they are thin, tend to
stretch and may become entangled in the deck mechanism.
Endless tapes:
Failure to operate these tapes correctly may cause the tape to wind
around the revolving parts.
For this unit, it is recommended to use the tape which is appropriate
to the auto reverse mechanism.
If the tape loosens, take up the slack A
Tape slack may cause the tape break.
To prevent erasure of recorded sounds E
To re-record on a protected cassette, cover the slot with adhesive
tape.
Do not cover the detection holes on high position tapes.
Improper tape storage:
You can damage tapes if you store them in the following places;
en high temperature [35°C (95°F) or higher] or high humidity (80%
or higher) areas
eIn a strong magnetic field (near a speaker, on top of TV, etc.)
This can erase a recording.
@ Areas exposed to direct sunlight
To erase sound previously recorded on a tape:
Disconnect the microphone.
1. Load the tape in deck 2.
2. Press W.
3. Press @/@ iI REC/REC PAUSE.
Tape head care
Gene
info
er
To assure sound quality for recording and playback, be sure to clean
the tape heads after approximately every 10 hours of use.
1. Open the cassette cover by pressing & DECK 1 and & DECK 2.
2. Clean the portions which contact the tape (the shaded portions in
the figure) with a cotton swab.
Do not use any solution other than alcohol for head cleaning.
